1042 Brocade Network Advisor SAN User Manual
53-1002948-01
Context-based flow definitions
30
Supported flow parameters by Flow Vision feature
Table 91 lists the supported basic flow configuration parameters for the Flow Vision Generator,
Monitor, and Mirror features.
Table 92 lists the supported advanced flow configuration parameters for the Flow Vision Generator,
Monitor, and Mirror applications.
Context-based flow definitions
Add Flow Definition dialog box fields and options are populated automatically to create the most
appropriate flow according to the context from which you launched the dialog box.You can launch
the dialog box from a switch port, initiator port, target port, or switch context using these options:
• Select the switch port, initiator port, target port, or switch on the products list or connectivity
map, then select Monitor > Flows > Add from the main menu bar.
• Right-click the switch port, initiator port, target port, or switch on the products list or
connectivity map, then select Flows > Add from the menu.
Table 93 describes the flow created and definition created in the Add Flow Definition dialog box
when launching the dialog box from a specific context.
NOTE
In general, * will be populated in source and destination device fields when the target switch
supports learning. Otherwise, these fields will be blank.
TABLE 91 Supported basic flow parameters for Flow Vision features
Parameter Flow Generator Flow Monitor Flow Mirror
Ingress port Supported Supported Supported
Egress port Supported Supported Supported
Source device Supported Supported Supported
Destination device Supported Supported Supported
Bidirectional Not applicable Supported Supported
TABLE 92 Supported advanced flow parameters for Flow Vision features
Parameter Flow Generator Flow Monitor Flow Mirror
LUN IDs Not applicable Supported Supported
Frame Type Not applicable Supported Supported
