Brocade Network Advisor SAN User Manual 1449
53-1002948-01
Database tables and fields
H
PVLAN_TYPE pvlan_type value for vlan.0- Normal VLAN. The
following are PVLAN Types applicable for NOS4.0 and
above.1- Primary PVLAN, 2- Isolated secondary
PVLAN, 3- Community secondary PVLAN. int
PRIMARY_VLAN_ID Private VLAN domain is built with one primary VLAN
and one or more secondary VLANs. This column
represents primary VLAN ID associated with this
secondary Isolated/Community VLAN (if PVLAN_TYPE
column value is 2 or 3) in private VLAN domain. For
primary VLAN (if PVLAN_TYPE column value is 1) in
private VLAN domain and normal VLAN (if
PVLAN_TYPE column value is 0) , then default value
(i.e 0) will be populated. int
TABLE 264 PRIVILEGE
Field Definition Format Size
ID* Unique generated database identifier. int
NAME Privilege Name. varchar 128
AREA Privilege Area.
0= Application
1= SAN
2= IP smallint
TABLE 265 PRODUCT_APP
Field Definition Format Size
ID* Unique generated database identifier. int
MENU_TEXT Name of the product menu. varchar 256
PROP1_KEY First condition name to be satisfied by a selected
product to launch a particular tool. varchar 256
PROP1_VALUE First condition value to be satisfied by a selected
product to launch a particular tool. varchar 256
PROP2_KEY Second condition name to be satisfied by a selected
product to launch a particular tool. varchar 256
PROP2_VALUE Second condition value to be satisfied by a selected
product to launch a particular tool. varchar 256
TOOL_ID The tool to be used for launching the application. int
PARAMETERS Link to that application. varchar 256
IP_SELECTED Selected IP Address option. smallint
WWN_SELECTED Selected WWN option. smallint
TABLE 263 PORT_VLAN (Continued)
Field Definition Format Size
