1068

Brocade Network Advisor SAN User Manual

53-1002948-01

Viewing policy monitor status

32

Viewing policy monitor status

You can view policy monitor status from the main Management application window or from the
Policy Monitor dialog box.

The Management application enables you to view the policy monitor status at a glance by providing
a policy monitor status icon on the Status Bar. The following table illustrates and describes the
icons that indicate the current status of the policy monitor function.

To view more detail regarding policy monitor status, click the Policy Monitor icon. The Policy Monitor
dialog box displays. For more information, refer to

“Viewing existing policy monitors”

on page 1068

Viewing existing policy monitors

To view existing policy monitors, complete the following steps.

1. Select Monitor > Policy Monitor (

Figure 446

).

The Policy Monitor dialog box displays.

FIGURE 446

Policy Monitor dialog box

TABLE 102

Policy Monitor Icons

Icon

Description

Passed — Displays when all

policy monitors, excluding un-alerted and acknowledged

monitors, pass.

Pause on icon to display flyover detail: Policy monitor is OK.

Failed — Displays when at least one policy monitor failed. Pause on icon to display flyover
detail: The last run of number policy monitor(s) has one or more failures.
