Accessing Flow Vision from other management application features
30
Table 99 describes how options are populated on the Add Flow Definition dialog box are populated
according to the row selected on the Reverse Route tab,
If first row is
selected (where
In Port Address
is source device
port's connected
switch port
address) Source Device = Source ID of source device port
Destination Device = * if port is on a 16-Gbps switch, otherwise
empty.
Ingress Port = ‘In’ port slot/port of selected row.
Target Switch = Switch of selected row.
Direction = Bidirectional
If last row is
selected (where
Out Port Address
is destination
device port’s
connected
switch port
address) Source Device = * if port is on a 16-Gbps switch, otherwise
empty.
Destination Device = * if port is on a 16-Gbps switch, otherwise
empty.
Ingress Port = ‘In’ port slot/port of selected row.
Target Switch = Switch of selected row.
Direction = Bidirectional
TABLE 99 Add Flow Definition dialog box options populated per Reverse Route selection
Port Selected Options populated
No rows
selected Source Device = Source ID from source device port
Destination Device = Destination ID from destination device port.
Target Switch = Switch in selected row.
Direction = Bidirectional
If first row is
selected (where
In Port Address
is destination
device port's
connected
switch port
address) Source Device = * if port is on a 16-Gbps switch, otherwise
empty.
Destination Device = Device ID from destination device port.
Ingress Port = ‘In’ port slot/port of selected row.
Target Switch = Switch of selected row.
Direction = Bidirectional
If last row is
selected (where
Out Port Address
is source device
port’s connected
switch port
address) Source Device = Source ID from source device port.
Destination Device = * if port is on a 16-Gbps switch, otherwise
empty.
Ingress Port = ‘Out’ port slot/port of selected row.
Target Switch = Switch of selected row.
Direction = Bidirectional
If selected row is
neither the first
or last row. Source Device = * if port is on a 16-Gbps switch, otherwise
empty.
Destination Device = * if port is on a 16-Gbps switch, otherwise
empty.
Ingress Port = ‘In’ port slot/port of selected row.
Target Switch = Switch of selected row.
Direction = Bidirectional
TABLE 98 Add Flow Definition dialog box options populated per Forward Route row selection
Row Selected Options populated
