Icon legend
8
Host group icons
The following table lists the manageable Host product group icons that display on the topology.
SAN port icons
The following table lists the port icons that display in the Product List.
SAN product status icons
The following table lists the product status icons that display on the topology.
TABLE 30
Icon Description Icon Description
Host Group
TABLE 31
Icon Description
Occupied FC Port
Unoccupied FC Port
Attached FC Port
Trunk (port group)
IP and 10 GE Port
Attached IP and 10 GE Port
Attached-to-Cloud 10 GE Port
Virtual Port
Virtual FCoE Port
Attached FCoE Port
Pre-boot Virtual Port
Virtual Attached Port
TABLE 32
Icon Status
No icon Healthy/Operational
Attention
Degraded/Marginal
Device Added
Device Removed/Missing
