Brocade Network Advisor SAN User Manual
1047
53-1002948-01
Accessing Flow Vision from other management application features
30
Refer to the Frame Viewer section of SAN Device Configuration chapter for more information on
accessing and using Frame Viewer and viewing discarded frames. Refer to
MAPS
Through the Traffic Monitoring category in the Monitoring and Alerting Policy Suite (MAPS) feature,
you can view a filtered list of MAPS violations for imported flows or sub-flows. You can also create
MAPS policies for events related to flows and sub-flows. For more information on accessing and
using the MAPS features, refer to
Chapter 34, “Monitoring and Alerting Policy Suite”
.
Bottleneck Detection
Select a port from the Bottlenecks dialog box and select Add Flow to launch the Add Flow Definition
dialog box. The Add Flow Definition dialog box will be populated with the following information when
available:
•
Source Device - *
•
Destination Device - *
•
Ingress port - Transmit port
•
Monitor - Bidirectional
describes how options on the Add Flow Definition dialog box are populated according to
the port selected on the Bottlenecks dialog box.
TABLE 97
Add Flow Definition dialog box options populated per Bottlenecks selection
Port Selected
Options populated
E_Port
Source Device = * if port is on a 16-Gbps-capable switch,
otherwise empty.
Destination Device = * if port is on a 16-Gbps switch, otherwise
empty.
Ingress Port = selected Port Number
Target Switch = Selected switch
Initiator
Source Device = Initiator port ID.
Destination Device = * if port is on a 16-Gbps switch, otherwise
empty.
Ingress Port = Selected port’s connected switch port number.
Target Switch = Selected port’s connected switch
Target
Source Device = * if port is on a 16-Gbps switch, otherwise
empty.
Destination Device = Target port ID.
Ingress Port = Selected port’s connected switch port number.
Target Switch = Selected port’s connected switch
If port other than
E_Port, initiator,
or target port
selected
Source Device = * if port is on a 16-Gbps switch, otherwise
empty.
Destination Device = * if port is on a 16-Gbps switch, otherwise
empty.
Ingress Port = Selected switch port number.
Target Switch = Selected switch
