310

9440500990 Rev D

Specifications

DECS-250N

RS-485

Type ................................................. RS-485, half duplex
Interface ........................................... Spring type terminals
Location ............................................ Left side panel
Terminals.......................................... RS-485 A, B, C

Ethernet

Type ................................................. 100Base-T copper (style xxxxx1x) or

100Base-FX (style xxxxx2x)

Interface ........................................... RJ45 jack (style xxxxx1x) or locking duplex ST (straight tip)

receptacle (style xxxxx2x)

Location ............................................ Right-side panel

Controller Area Network (CAN)

Type ................................................. SAE J1939 message protocol
Interface ........................................... Spring (style xxxSxxx) or compression (style xxxCxxx) type terminals
Location ............................................ Right side panel
Terminals.......................................... CAN 1 H, L, SH

CAN 2 H, L, SH

Differential Bus Voltage .................... 1.5 to 3 Vdc
Maximum Voltage ............................ –32 to +32 Vdc
Communication Rate ........................ 250 kb/s

IRIG Time Synchronization Input

Standard ........................................... 200-98, Format B002, and 200-04, Format B006
Input Signal ...................................... Demodulated (dc level-shifted signal)
Logic High Level ............................... 3.5 Vdc, minimum
Logic Low Level ............................... 0.5 Vdc, maximum
Input Voltage Range ........................ –10 to +10 Vdc
Input Resistance .............................. Nonlinear, approximately 4 k

Ω at 3.5 Vdc,

3 k

Ω at 20 Vdc

Response Time ................................ <1 cycle
Terminals.......................................... IRIG+, IRIG–

Contact Outputs

Make and Break Ratings (Resistive)

24 Vdc ........................................ 7.0 Adc

48 Vdc ........................................ 0.7 Adc

125 Vdc ...................................... 0.2 Adc

120/240 Vac ............................... 7.0 Aac

Carry Ratings (Resistive)

24/48/125 Vdc ............................ 7.0 Adc

120/240 Vac ............................... 7.0 Aac

Terminal Assignments

Watchdog ................................... WTCHD1, WTCHD, WTCHD2

Relay Output 1 ........................... RLY 1, RLY 1

Relay Output 2 ........................... RLY 2, RLY 2

Relay Output 3 ........................... RLY 3, RLY 3

Relay Output 4 ........................... RLY 4, RLY 4

Relay Output 5 ........................... RLY 5, RLY 5

Relay Output 6 ........................... RLY 6, RLY 6

Relay Output 7 ........................... RLY 7, RLY 7

Relay Output 8 ........................... RLY 8, RLY 8

Relay Output 9 ........................... RLY 9, RLY 9
