9440500990 Rev D 245
DECS-250N PROFIBUS Communication
Table 38. Instance 11 Parameters
Instance Name Inst. # Type RW Key Name Range
Local Contact Outputs Cyclic 11 UINT8 R CONTACTOUTPUTS_
WATCHDOGOUTPUT Open=0, Closed=1
Local Contact Outputs Cyclic 11 UINT8 R CONTACTOUTPUTS_OUTPUT1 Open=0, Closed=1
Local Contact Outputs Cyclic 11 UINT8 R CONTACTOUTPUTS_OUTPUT2 Open=0, Closed=1
Local Contact Outputs Cyclic 11 UINT8 R CONTACTOUTPUTS_OUTPUT3 Open=0, Closed=1
Local Contact Outputs Cyclic 11 UINT8 R CONTACTOUTPUTS_OUTPUT4 Open=0, Closed=1
Local Contact Outputs Cyclic 11 UINT8 R CONTACTOUTPUTS_OUTPUT5 Open=0, Closed=1
Local Contact Outputs Cyclic 11 UINT8 R CONTACTOUTPUTS_OUTPUT6 Open=0, Closed=1
Local Contact Outputs Cyclic 11 UINT8 R CONTACTOUTPUTS_OUTPUT7 Open=0, Closed=1
Local Contact Outputs Cyclic 11 UINT8 R CONTACTOUTPUTS_OUTPUT8 Open=0, Closed=1
Local Contact Outputs Cyclic 11 UINT8 R CONTACTOUTPUTS_OUTPUT9 Open=0, Closed=1
Local Contact Outputs Cyclic 11 UINT8 R CONTACTOUTPUTS_OUTPUT10 Open=0, Closed=1
Local Contact Outputs Cyclic 11 UINT8 R CONTACTOUTPUTS_OUTPUT11 Open=0, Closed=1
Table 39 shows the bit number of each parameter in instance 11 and an example packet returned from a
DECS-250N. Reading a value of 0xA4 06 (1010 0100 0000 0110) for instance 11 indicates that contact
outputs 2, 5, 7, 9, and 10 are closed. The first byte is 1010 0100 and the second is 0000 0110.
Table 39. Instance 11 Bit Order
Instance
Number
Byte Number
Bit Number Key Name
Packet Returned from
DECS-250N
11 1 0 CONTACTOUTPUTS_WATCHDOG 0
1 CONTACTOUTPUTS_OUTPUT1 0
2 CONTACTOUTPUTS_OUTPUT2 1
3 CONTACTOUTPUTS_OUTPUT3 0
4 CONTACTOUTPUTS_OUTPUT4 0
5 CONTACTOUTPUTS_OUTPUT5 1
6 CONTACTOUTPUTS_OUTPUT6 0
7 CONTACTOUTPUTS_OUTPUT7 1
2 0 CONTACTOUTPUTS_OUTPUT8 0
1 CONTACTOUTPUTS_OUTPUT9 1
2 CONTACTOUTPUTS_OUTPUT10 1
3 CONTACTOUTPUTS_OUTPUT11 0
4 0 (unused) 0
5 0 (unused) 0
6 0 (unused) 0
7 0 (unused) 0
Setup
The following steps are provided to assist in setting up the DECS-250N as a slave on a PROFIBUS
network. Please refer to the documentation included with your PLC configuration software for installation
and operation instructions.
1. Download the DECS-250N GSD file from the Basler website: www.basler.com
