120 9440500990 Rev D
Terminals and Connectors DECS-250N
Terminal
Block
Maximum
Wire Size
Compression Terminals Spring Terminals
M 16 AWG
1.5 mm
2 (solid
and stranded)
N/A N/A 0.35 in (9 mm)
Spring terminal connector blocks identified by locators A through J and M are held in place by retaining
clips.
Connectors identified by locators A, B, E, F, G, H, I, and J are keyed to avoid misconnections.
