170 9440500990 Rev D
Communication DECS-250N
PROFIBUS Communication
BESTCOMSPlus Navigation Path: Settings Explorer, Communications, Profibus Setup
HMI Navigation Path: Settings, Communications, Profibus
On units equipped with the PROFIBUS communication protocol (style xxxxxxP), the DECS-250N sends
and receives PROFIBUS data through a DB-9 port located on the right side panel. DECS-250N
PROFIBUS communication parameters are listed and defined in the PROFIBUS Communication chapter
of this manual.
DB-9 port communication settings are illustrated in Figure 148 and consist of the address A and network
byte order B .
Figure 148. Profibus Setup
A Address: Adjustable from 0 to 126 in increments of 1.
B Network Byte Order: MSB First or LSB First.
