218 9440500990 Rev D
Modbus™ Communication DECS-250N
Group Name Register Type Bytes R/W Range
Network Load Share Receiving ID 3 40927 bit 0 Uint16 2 R True=1 False=0
Network Load Share Receiving ID 4 40927 bit 1 Uint16 2 R True=1 False=0
Network Load Share Receiving ID 5 40927 bit 2 Uint16 2 R True=1 False=0
Network Load Share Receiving ID 6 40927 bit 3 Uint16 2 R True=1 False=0
Network Load Share Receiving ID 7 40927 bit 4 Uint16 2 R True=1 False=0
Network Load Share Receiving ID 8 40927 bit 5 Uint16 2 R True=1 False=0
Network Load Share Receiving ID 9 40927 bit 6 Uint16 2 R True=1 False=0
Network Load Share Receiving ID 10 40927 bit 7 Uint16 2 R True=1 False=0
Network Load Share Receiving ID 11 40927 bit 8 Uint16 2 R True=1 False=0
Network Load Share Receiving ID 12 40927 bit 9 Uint16 2 R True=1 False=0
Network Load Share Receiving ID 13 40927 bit 10 Uint16 2 R True=1 False=0
Network Load Share Receiving ID 14 40927 bit 11 Uint16 2 R True=1 False=0
Network Load Share Receiving ID 15 40927 bit 12 Uint16 2 R True=1 False=0
Network Load Share Receiving ID 16 40927 bit 13 Uint16 2 R True=1 False=0
Network Load Share NLS Configuration Mismatch 40927 bit 14 Uint16 2 R True=1 False=0
Network Load Share NLS ID Missing 40927 bit 15 Uint16 2 R True=1 False=0
Network Load Share ID 1 Enabled 40928 bit 0 Uint16 2 R True=1 False=0
Network Load Share ID 2 Enabled 40928 bit 1 Uint16 2 R True=1 False=0
Network Load Share ID 3 Enabled 40928 bit 2 Uint16 2 R True=1 False=0
Network Load Share ID 4 Enabled 40928 bit 3 Uint16 2 R True=1 False=0
Network Load Share ID 5 Enabled 40928 bit 4 Uint16 2 R True=1 False=0
Network Load Share ID 6 Enabled 40928 bit 5 Uint16 2 R True=1 False=0
Network Load Share ID 7 Enabled 40928 bit 6 Uint16 2 R True=1 False=0
Network Load Share ID 8 Enabled 40928 bit 7 Uint16 2 R True=1 False=0
Network Load Share ID 9 Enabled 40928 bit 8 Uint16 2 R True=1 False=0
Network Load Share ID 10 Enabled 40928 bit 9 Uint16 2 R True=1 False=0
Network Load Share ID 11 Enabled 40928 bit 10 Uint16 2 R True=1 False=0
Network Load Share ID 12 Enabled 40928 bit 11 Uint16 2 R True=1 False=0
Network Load Share ID 13 Enabled 40928 bit 12 Uint16 2 R True=1 False=0
Network Load Share ID 14 Enabled 40928 bit 13 Uint16 2 R True=1 False=0
Network Load Share ID 15 Enabled 40928 bit 14 Uint16 2 R True=1 False=0
Network Load Share ID 16 Enabled 40928 bit 15 Uint16 2 R True=1 False=0
Network Load Share NLS Status 1 40929 bit 0 Uint16 2 R True=1 False=0
Network Load Share NLS Status 2 40929 bit 1 Uint16 2 R True=1 False=0
Network Load Share NLS Status 3 40929 bit 2 Uint16 2 R True=1 False=0
Network Load Share NLS Status 4 40929 bit 3 Uint16 2 R True=1 False=0
Metering
Table 27. Metering Group Parameters
Group Name Register Type Bytes R/W Unit Range
Field Voltage Meter V
X
41000 Float 4 R Volt -1000 - 1000
Field Current Meter I
X
41002 Float 4 R Amp 0 - 2000000000
DECS PSS Meter Terminal Frequency Deviation 41004 Float 4 R n/a n/a
DECS PSS Meter Compensated Frequency
Deviation 41006 Float 4 R n/a n/a
DECS PSS Meter PSS output 41008 Float 4 R n/a n/a
DECS Regulator Meter Tracking error 41010 Float 4 R Percent n/a
DECS Regulator Meter Control output PU 41012 Float 4 R n/a -10 - 10
DECS Regulator Meter Exciter Diode Monitor Ripple
Percent 41014 Float 4 R Percent n/a
DECS Regulator Meter Power Input 41016 Float 4 R Volt 0 - 2000000000
