9440500990 Rev D 203
DECS-250N Modbus™ Communication
DECS-250N Modbus
™ via Ethernet
Modbus can communicate through Ethernet if the IP address of the DECS-250N is configured as
described in the Communications chapter of this manual.
Detailed Message Query and Response for RTU Transmission Mode
A detailed description of DECS-250N supported message queries and responses is provided in the
following paragraphs.
Read Holding Registers
Query
This query message requests a register or block of registers to be read. The data block contains the
starting register address and the quantity of registers to be read. A register address of N will read holding
register N+1. If the query is a broadcast (device address = 0), no response message is returned.
Device Address
Function Code =
03 (hex)
Starting Address Hi
Starting Address Lo
No. of Registers Hi
No. of Registers Lo
CRC Hi error check
CRC Lo error check
The number of registers cannot exceed 125 without causing an error response with the exception code
for an illegal function.
Response
The response message contains the data queried. The data block contains the block length in bytes
followed by the data (one Data Hi byte and one Data Lo byte) for each requested register.
Reading an unassigned holding register returns a value of zero.
Device Address
Function Code =
03 (hex)
Byte Count
Data Hi (For each requested register, there is one Data Hi and one Data Lo.)
Data Lo
.
.
Data Hi
Data Lo
CRC Hi error check
CRC Lo error check
Return Query Data
This query contains data to be returned (looped back) in the response. The response and query
messages should be identical. If the query is a broadcast (device address = 0), no response message is
returned.
Device Address
Function Code =
08 (hex)
Subfunction Hi = 00 (hex)
Subfunction Lo = 00 (hex)
Data Hi = xx (don't care)
Data Lo = xx (don't care)
CRC Hi error check
