196 9440500990 Rev D
CAN Communication DECS-250N
PGN Name Units SPN
Broadcast
Rate
0xFE05 Generator Total Real Power Watts 2452 100 ms
Generator Total Apparent Power VA 2460
0xFF00 Contact I/O Status
Start Input - Byte 0, bits 0,1
Stop Input - Byte 0, bits 2,3
Input 1 - Byte 0, bits 4,5
Input 2 - Byte 0, bits 6,7
Input 3 - Byte 1, bits 0,1
Input 4 - Byte 1, bits 2,3
Input 5 - Byte 1, bits 4,5
Input 6 - Byte 1, bits 6,7
Input 7 - Byte 2, bits 0,1
Input 8 - Byte 2, bits 2,3
Input 9 - Byte 2, bits 4,5
Input 10 - Byte 2, bits 6,7
Input 11 - Byte 3, bits 0,1
Input 12 - Byte 3, bits 2,3
Input 13 - Byte 3, bits 4,5
Input 14 - Byte 3, bits 6,7
Watchdog Output - Byte 4, bits 0,1
Output 1 - Byte 4, bits 2,3
Output 2 - Byte 4, bits 4,5
Output 3 - Byte 4, bits 6,7
Output 4 - Byte 5, bits 0,1
Output 5 - Byte 5, bits 2,3
Output 6 - Byte 5, bits 4,5
Output 7 - Byte 5, bits 6,7
Output 8 - Byte 6, bits 0,1
Output 9 - Byte 6, bits 2,3
Output 10 - Byte 6, bits 4,5
Output 11 - Byte 6, bits 6,7
Notes
0 = Open
1 = Closed
2 = Reserved
3 = Reserved
n/a n/a 100 ms
0xFF01 Requested Generator Excitation Field Voltage (FVR Setpoint) Volts 3380 n/a
Requested Generator Excitation Field Current (FCR Setpoint) Amps 3381 n/a
0xFF02
Requested Operating Mode
Byte 0, Bits 0-2
Notes
1 = FCR
2 = AVR
3 = VAR
4 = PF
5 = FVR
Will not override if held by logic.
Byte 0, Bits 3-7 unused
Bytes 1-7 unused
n/a n/a 100 ms
0xF015 Requested Generator Total AC Reactive Power (var Setpoint) var 3383 n/a
Requested Generator Overall PF (PF Setpoint) n/a 3384 n/a
Requested Generator Overall PF Lagging (PF Setpoint) n/a 3385 n/a
0xF01C Requested Generator Average L-L AC RMS Voltage
(AVR Setpoint) Volts 3386 n/a
