204 9440500990 Rev D
Modbus™ Communication DECS-250N
CRC Lo error check
Restart Communications Option
This query causes the remote communications function of the DECS-250N to restart, terminating an
active listen only mode of operation. No effect is made upon primary relay operations. Only the remote
communications function is affected. If the query is a broadcast (device address = 0), no response
message is returned.
If the DECS-250N receives this query while in the listen only mode, no response message is generated.
Otherwise, a response message identical to the query message is transmitted prior to the
communications restart.
Device Address
Function Code =
08 (hex)
Subfunction Hi = 00 (hex)
Subfunction Lo = 01 (hex)
Data Hi = xx (don't care)
Data Lo = xx (don't care)
CRC Hi error check
CRC Lo error check
Listen Only Mode
This query forces the addressed DECS-250N to the listen only mode for Modbus communications,
isolating it from other devices on the network. No responses are returned.
While in the listen only mode, the DECS-250N continues to monitor all queries. The DECS-250N does not
respond to any other query until the listen only mode is removed. All write requests with a query to Preset
Multiple Registers (Function Code = 16) are also ignored. When the DECS-250N receives the restart
communications query, the listen only mode is removed.
Device Address
Function Code =
08 (hex)
Subfunction Hi = 00 (hex)
Subfunction Lo = 04 (hex)
Data Hi = xx (don't care)
Data Lo = xx (don't care)
CRC Hi error check
CRC Lo error check
Preset Multiple Registers
A preset multiple registers query could address multiple registers in one slave or multiple slaves. If the
query is a broadcast (device address = 0), no response message is returned.
Query
A Preset Multiple Register query message requests a register or block of registers to be written. The data
block contains the starting address and the quantity of registers to be written, followed by the Data Block
byte count and data. The will perform the write when the device address in query is a broadcast address
or the same as the DECS-250N Modbus Unit ID (device address).
A register address of N will write Holding Register N+1.
Data will cease to be written if any of the following exceptions occur.
•
Queries to write to Read Only registers result in an error response with Exception Code of “Illegal
Data Address”.
•
Queries attempting to write more than 100 registers cause an error response with Exception Code
“Illegal Function”.
•
An incorrect Byte Count will result in an error response with Exception Code of “Illegal Data Value”.
