9440500990 Rev D 253
DECS-250N PROFIBUS Communication
Instance Name Inst. # Type RW Key Name Unit Range
AEM Analog Input Meter 34 Float R AnalogInput1ScaledValue GG No Unit -9999 - 9999
AEM Analog Input Meter 34 Float R AnalogInput2ScaledValue GG No Unit -9999 – 9999
AEM Analog Input Meter 34 Float R AnalogInput3ScaledValue GG No Unit -9999 – 9999
AEM Analog Input Meter 34 Float R AnalogInput4ScaledValue GG No Unit -9999 – 9999
AEM Analog Input Meter 34 Float R AnalogInput5ScaledValue GG No Unit -9999 – 9999
AEM Analog Input Meter 34 Float R AnalogInput6ScaledValue GG No Unit -9999 – 9999
AEM Analog Input Meter 34 Float R AnalogInput7ScaledValue GG No Unit -9999 – 9999
AEM Analog Input Meter 34 Float R AnalogInput8ScaledValue GG No Unit -9999 – 9999
AEM Analog Input Status 35 UINT8 R AEMCONFIG AEM INPUT 1
OUT OF RANGE Value in range=0, Value out of
range=1
AEM Analog Input Status 35 UINT8 R AEMCONFIG AEM INPUT 2
OUT OF RANGE Value in range=0, Value out of
range=1
AEM Analog Input Status 35 UINT8 R AEMCONFIG AEM INPUT 3
OUT OF RANGE Value in range=0, Value out of
range=1
AEM Analog Input Status 35 UINT8 R AEMCONFIG AEM INPUT 4
OUT OF RANGE Value in range=0, Value out of
range=1
AEM Analog Input Status 35 UINT8 R AEMCONFIG AEM INPUT 5
OUT OF RANGE Value in range=0, Value out of
range=1
AEM Analog Input Status 35 UINT8 R AEMCONFIG AEM INPUT 6
OUT OF RANGE Value in range=0, Value out of
range=1
AEM Analog Input Status 35 UINT8 R AEMCONFIG AEM INPUT 7
OUT OF RANGE Value in range=0, Value out of
range=1
AEM Analog Input Status 35 UINT8 R AEMCONFIG AEM INPUT 8
OUT OF RANGE Value in range=0, Value out of
range=1
AEM Analog Input Status 35 UINT8 R AEMPROTECTION1
THRESH1 TRIP Not tripped-0, Tripped=1
AEM Analog Input Status 35 UINT8 R AEMPROTECTION1
THRESH2 TRIP Not tripped-0, Tripped=1
AEM Analog Input Status 35 UINT8 R AEMPROTECTION1
THRESH3 TRIP Not tripped-0, Tripped=1
AEM Analog Input Status 35 UINT8 R AEMPROTECTION1
THRESH4 TRIP Not tripped-0, Tripped=1
AEM Analog Input Status 35 UINT8 R AEMPROTECTION2
THRESH1 TRIP Not tripped-0, Tripped=1
AEM Analog Input Status 35 UINT8 R AEMPROTECTION2
THRESH2 TRIP Not tripped-0, Tripped=1
AEM Analog Input Status 35 UINT8 R AEMPROTECTION2
THRESH3 TRIP Not tripped-0, Tripped=1
AEM Analog Input Status 35 UINT8 R AEMPROTECTION2
THRESH4 TRIP Not tripped-0, Tripped=1
AEM Analog Input Status 35 UINT8 R AEMPROTECTION3
THRESH1 TRIP Not tripped-0, Tripped=1
AEM Analog Input Status 35 UINT8 R AEMPROTECTION3
THRESH2 TRIP Not tripped-0, Tripped=1
AEM Analog Input Status 35 UINT8 R AEMPROTECTION3
THRESH3 TRIP Not tripped-0, Tripped=1
AEM Analog Input Status 35 UINT8 R AEMPROTECTION3
THRESH4 TRIP Not tripped-0, Tripped=1
AEM Analog Input Status 35 UINT8 R AEMPROTECTION4
THRESH1 TRIP Not tripped-0, Tripped=1
AEM Analog Input Status 35 UINT8 R AEMPROTECTION4
THRESH2 TRIP Not tripped-0, Tripped=1
AEM Analog Input Status 35 UINT8 R AEMPROTECTION4
THRESH3 TRIP Not tripped-0, Tripped=1
AEM Analog Input Status 35 UINT8 R AEMPROTECTION4
THRESH4 TRIP Not tripped-0, Tripped=1
AEM Analog Input Status 35 UINT8 R AEMPROTECTION5
THRESH1 TRIP Not tripped-0, Tripped=1
AEM Analog Input Status 35 UINT8 R AEMPROTECTION5
THRESH2 TRIP Not tripped-0, Tripped=1
