256 9440500990 Rev D
PROFIBUS Communication DECS-250N
Instance Name Inst. # Type RW Key Name Unit Range
AEM RTD Input Status 37 UINT8 R RTDPROTECTION7
THRESH4 TRIP Not tripped=0, Tripped=1
AEM RTD Input Status 37 UINT8 R RTDPROTECTION8
THRESH1 TRIP Not tripped=0, Tripped=1
AEM RTD Input Status 37 UINT8 R RTDPROTECTION8
THRESH2 TRIP Not tripped=0, Tripped=1
AEM RTD Input Status 37 UINT8 R RTDPROTECTION8
THRESH3 TRIP Not tripped=0, Tripped=1
AEM RTD Input Status 37 UINT8 R RTDPROTECTION8
THRESH4 TRIP Not tripped=0, Tripped=1
AEM TC Input Meter 38 Float R ThermInput1RawValue GG mV n/a
AEM TC Input Meter 38 Float R ThermInput2RawValue GG mV n/a
AEM TC Input Meter 38 Float R ThermInput1ScaledValue GG Deg F n/a
AEM TC Input Meter 38 Float R ThermInput2ScaledValue GG Deg F n/a
AEM TC Input Status 39 UINT8 R AEMCONFIG THERMAL
COUPLE 1
OUT OF RANGE Value in range=0, Value out of
range=1
AEM TC Input Status 39 UINT8 R AEMCONFIG THERMAL
COUPLE 2
OUT OF RANGE Value in range=0, Value out of
range=1
AEM TC Input Status 39 UINT8 R THERMPROTECTION1
THRESH1 TRIP Not tripped=0, Tripped=1
AEM TC Input Status 39 UINT8 R THERMPROTECTION1
THRESH2 TRIP Not tripped=0, Tripped=1
AEM TC Input Status 39 UINT8 R THERMPROTECTION1
THRESH3 TRIP Not tripped=0, Tripped=1
AEM TC Input Status 39 UINT8 R THERMPROTECTION1
THRESH4 TRIP Not tripped=0, Tripped=1
AEM TC Input Status 39 UINT8 R THERMPROTECTION2
THRESH1 TRIP Not tripped=0, Tripped=1
AEM TC Input Status 39 UINT8 R THERMPROTECTION2
THRESH2 TRIP Not tripped=0, Tripped=1
AEM TC Input Status 39 UINT8 R THERMPROTECTION2
THRESH3 TRIP Not tripped=0, Tripped=1
AEM TC Input Status 39 UINT8 R THERMPROTECTION2
THRESH4 TRIP Not tripped=0, Tripped=1
Contact Output Status 40 UINT8 R CONTACTOUTPUTS
WATCHDOGOUTPUT Open=0, Closed=1
Contact Output Status 40 UINT8 R CONTACTOUTPUTS
OUTPUT1 Open=0, Closed=1
Contact Output Status 40 UINT8 R CONTACTOUTPUTS
OUTPUT2 Open=0, Closed=1
Contact Output Status 40 UINT8 R CONTACTOUTPUTS
OUTPUT3 Open=0, Closed=1
Contact Output Status 40 UINT8 R CONTACTOUTPUTS
OUTPUT4 Open=0, Closed=1
Contact Output Status 40 UINT8 R CONTACTOUTPUTS
OUTPUT5 Open=0, Closed=1
Contact Output Status 40 UINT8 R CONTACTOUTPUTS
OUTPUT6 Open=0, Closed=1
Contact Output Status 40 UINT8 R CONTACTOUTPUTS
OUTPUT7 Open=0, Closed=1
Contact Output Status 40 UINT8 R CONTACTOUTPUTS
OUTPUT8 Open=0, Closed=1
Contact Output Status 40 UINT8 R CONTACTOUTPUTS
OUTPUT9 Open=0, Closed=1
Contact Output Status 40 UINT8 R CONTACTOUTPUTS
OUTPUT10 Open=0, Closed=1
Contact Output Status 40 UINT8 R CONTACTOUTPUTS
OUTPUT11 Open=0, Closed=1
CEM Output Status 41 UINT8 R CEM OUTPUT 1 Open=0, Closed=1
