266 9440500990 Rev D
PROFIBUS Communication DECS-250N
Instance Name Inst. # Type RW Key Name Unit Range
OEL Takeover 112 Float R/W Oel Sec Takeover
Cur Min Off GG
Amp 0 - 15
OEL Takeover 112 Float R/W Oel Sec Takeover
Time Dial Off GG
No
Unit
0.1 - 20
OEL Takeover 112 Float R/W Oel Sec Takeover
Cur Max On GG
Amp 0 - 30
OEL Takeover 112 Float R/W Oel Sec Takeover
Cur Min On GG
Amp 0 - 15
OEL Takeover 112 Float R/W Oel Sec Takeover
Time Dial On GG
No
Unit
0.1 - 20
UEL Configure 113 UINT32 R/W Sys Option Input
Uel Enabled GG
No
Unit
DISABLED=0 ENABLED=1
UEL Configure 114 Float R/W Uel Pri Pow Filter TC GG Sec 0 - 20
UEL Configure 114 Float R/W Uel Pri Volt Dep
Exponent GG
No
Unit
0 - 2
UEL Curve Float Primary 116 Float R/W Uel Pri Curve X1 GG KW 0 - 62
UEL Curve Float Primary 116 Float R/W Uel Pri Curve X2 GG KW 0 - 62
UEL Curve Float Primary 116 Float R/W Uel Pri Curve X3 GG KW 0 - 62
UEL Curve Float Primary 116 Float R/W Uel Pri Curve X4 GG KW 0 - 62
UEL Curve Float Primary 116 Float R/W Uel Pri Curve X5 GG KW 0 - 62
UEL Curve Float Primary 116 Float R/W Uel Pri Curve Y1 GG kvar 0 - 62
UEL Curve Float Primary 116 Float R/W Uel Pri Curve Y2 GG kvar 0 - 62
UEL Curve Float Primary 116 Float R/W Uel Pri Curve Y3 GG kvar 0 - 62
UEL Curve Float Primary 116 Float R/W Uel Pri Curve Y4 GG kvar 0 - 62
UEL Curve Float Primary 116 Float R/W Uel Pri Curve Y5 GG kvar 0 - 62
UEL Curve Float Secondary 118 Float R/W Uel Sec Curve X1 GG KW 0 - 62
UEL Curve Float Secondary 118 Float R/W Uel Sec Curve X2 GG KW 0 - 62
UEL Curve Float Secondary 118 Float R/W Uel Sec Curve X3 GG KW 0 - 62
UEL Curve Float Secondary 118 Float R/W Uel Sec Curve X4 GG KW 0 - 62
UEL Curve Float Secondary 118 Float R/W Uel Sec Curve X5 GG KW 0 - 62
UEL Curve Float Secondary 118 Float R/W Uel Sec Curve Y1 GG kvar 0 - 62
UEL Curve Float Secondary 118 Float R/W Uel Sec Curve Y2 GG kvar 0 - 62
UEL Curve Float Secondary 118 Float R/W Uel Sec Curve Y3 GG kvar 0 - 62
UEL Curve Float Secondary 118 Float R/W Uel Sec Curve Y4 GG kvar 0 - 62
UEL Curve Float Secondary 118 Float R/W Uel Sec Curve Y5 GG kvar 0 - 62
SCL Settings 119 UINT32 R/W Sys Option Input Scl
Enabled GG
No
Unit
DISABLED=0 ENABLED=1
SCL Settings 120 Float R/W Scl Pri Ref Hi GG Amp 0 - 66000
SCL Settings 120 Float R/W Scl Pri Ref Lo GG Amp 0 - 66000
