9440500990 Rev D 141
DECS-250N BESTlogic
™Plus
Name Description Symbol
Remote Inputs
IN15 - IN24 True when Remote Input x is active.
(Available when an optional CEM-2020 is
connected.)
Virtual Inputs
VIN1 - VIN6 True when Virtual Input x is active.
Status Inputs
Anticipatory Sync
Selected True when Anticipatory is selected. (Synchronizer
screen)
Auto Mode Active True when the unit is in Auto mode (AVR).
Bus Dead True when the Bus Dead condition settings have
been exceeded. (Available when the controller is
equipped with the optional Auto synchronizer, style
number xxxxAxx)
Bus Failed True when the Bus Stable condition settings are
not met. (Available when the controller is equipped
with the optional Auto synchronizer, style number
xxxxAxx)
Bus Stable True when the Bus Stable condition settings have
been exceeded. (Available when the controller is
equipped with the optional Auto synchronizer, style
number xxxxAxx)
Auto Sync
Enabled True when DECS auto-sync is enabled. (Available
when the controller is equipped with the optional
Auto synchronizer, style number xxxxAxx)
Crowbar
Activated True when the crowbar is active.
Dead Bus Close
Request True when this option is user-enabled; a dead bus
is closed automatically upon detection. False when
this option is disabled; a dead bus will remain
open. (Available when the controller is equipped
with the optional Auto synchronizer, style number
xxxxAxx)
External Tracking
Active True when external tracking is running.
Failed To Buildup True when the Failed to Buildup alarm is active.
FCR Active True when the unit is in FCR mode.
Field Flash Active True when field flash is active.
Field Short
Circuit Status True when a field short circuit condition is detected.
FVR Active True when the unit is in FVR mode.
