Basler Electric DECS-250N - Manual (Page 226)

210 9440500990 Rev D
Modbus™ Communication DECS-250N
Group Name Register Type Bytes R/W Range
Alarms Programmable Alarm 9 40901 bit 8 Uint16 2 R True=1 False=0
Alarms Programmable Alarm 10 40901 bit 9 Uint16 2 R True=1 False=0
Alarms Programmable Alarm 11 40901 bit 10 Uint16 2 R True=1 False=0
Alarms Programmable Alarm 12 40901 bit 11 Uint16 2 R True=1 False=0
Alarms Programmable Alarm 13 40901 bit 12 Uint16 2 R True=1 False=0
Alarms Programmable Alarm 14 40901 bit 13 Uint16 2 R True=1 False=0
Alarms Programmable Alarm 15 40901 bit 14 Uint16 2 R True=1 False=0
Alarms Programmable Alarm 16 40901 bit 15 Uint16 2 R True=1 False=0
Alarms Underfrequency V/Hz Alarm 40902 bit 0 Uint16 2 R True=1 False=0
Alarms OEL alarm 40902 bit 1 Uint16 2 R True=1 False=0
Alarms UEL alarm 40902 bit 2 Uint16 2 R True=1 False=0
Alarms Failed to build up alarm 40902 bit 3 Uint16 2 R True=1 False=0
Alarms SCL alarm 40902 bit 4 Uint16 2 R True=1 False=0
Alarms PSS voltage unbalanced alarm 40902 bit 5 Uint16 2 R True=1 False=0
Alarms PSS current unbalanced alarm 40902 bit 6 Uint16 2 R True=1 False=0
Alarms PSS power below threshold alarm 40902 bit 7 Uint16 2 R True=1 False=0
Alarms PSS speed failed alarm 40902 bit 8 Uint16 2 R True=1 False=0
Alarms PSS voltage limit alarm 40902 bit 9 Uint16 2 R True=1 False=0
Alarms Transfer watchdog alarm 40902 bit 10 Uint16 2 R True=1 False=0
Alarms Crowbar activated 40902 bit 11 Uint16 2 R True=1 False=0
Alarms Var limiter active alarm 40902 bit 12 Uint16 2 R True=1 False=0
Alarm Report Alarm Output 40902 bit 13 Uint16 2 R True=1 False=0
Hardware Ports Field Short Circuit Status 40902 bit 14 Uint16 2 R True=1 False=0
DECS Control Auto transfer enable 40902 bit 15 Uint16 2 R True=1 False=0
DECS Control Var PF selection 40903 bit 0 Uint16 2 R True=1 False=0
DECS Control DECS start stop (external) 40903 bit 1 Uint16 2 R True=1 False=0
DECS Control Pre-position 1 active 40903 bit 2 Uint16 2 R True=1 False=0
DECS Control Pre-position 2 active 40903 bit 3 Uint16 2 R True=1 False=0
DECS Control Pre-position 3 active 40903 bit 4 Uint16 2 R True=1 False=0
DECS Control Auto active 40903 bit 5 Uint16 2 R True=1 False=0
Field Overvoltage Block 40903 bit 6 Uint16 2 R True=1 False=0
Field Overvoltage Pickup 40903 bit 7 Uint16 2 R True=1 False=0
Field Overvoltage Trip 40903 bit 8 Uint16 2 R True=1 False=0
Field Overcurrent Block 40903 bit 9 Uint16 2 R True=1 False=0
Field Overcurrent Pickup 40903 bit 10 Uint16 2 R True=1 False=0
Field Overcurrent Trip 40903 bit 11 Uint16 2 R True=1 False=0
Exciter Diode Monitor Block open diode 40903 bit 12 Uint16 2 R True=1 False=0
Exciter Diode Monitor Pickup open diode 40903 bit 13 Uint16 2 R True=1 False=0
Exciter Diode Monitor Trip open diode 40903 bit 14 Uint16 2 R True=1 False=0
Exciter Diode Monitor Block shorted diode 40903 bit 15 Uint16 2 R True=1 False=0
Exciter Diode Monitor Pickup shorted diode 40904 bit 0 Uint16 2 R True=1 False=0
Exciter Diode Monitor Trip shorted diode 40904 bit 1 Uint16 2 R True=1 False=0
Power Input Failure Block 40904 bit 2 Uint16 2 R True=1 False=0
Power Input Failure Pickup 40904 bit 3 Uint16 2 R True=1 False=0
Power Input Failure Trip 40904 bit 4 Uint16 2 R True=1 False=0
Loss of Sensing Block 40904 bit 5 Uint16 2 R True=1 False=0
Loss of Sensing Pickup 40904 bit 6 Uint16 2 R True=1 False=0
Loss of Sensing Trip 40904 bit 7 Uint16 2 R True=1 False=0
25 Block 40904 bit 8 Uint16 2 R True=1 False=0
25 Status 40904 bit 9 Uint16 2 R True=1 False=0
25 VM1 status 40904 bit 10 Uint16 2 R True=1 False=0
