212 9440500990 Rev D
Modbus™ Communication DECS-250N
Group Name Register Type Bytes R/W Range
Configurable Protection 4 Configurable Protection Threshold 4 Pickup 40907 bit 14 Uint16 2 R True=1 False=0
Configurable Protection 4 Configurable Protection Threshold 4 Trip 40907 bit 15 Uint16 2 R True=1 False=0
Configurable Protection 5 Configurable Protection Threshold 1 Pickup 40908 bit 0 Uint16 2 R True=1 False=0
Configurable Protection 5 Configurable Protection Threshold 1 Trip 40908 bit 1 Uint16 2 R True=1 False=0
Configurable Protection 5 Configurable Protection Threshold 2 Pickup 40908 bit 2 Uint16 2 R True=1 False=0
Configurable Protection 5 Configurable Protection Threshold 2 Trip 40908 bit 3 Uint16 2 R True=1 False=0
Configurable Protection 5 Configurable Protection Threshold 3 Pickup 40908 bit 4 Uint16 2 R True=1 False=0
Configurable Protection 5 Configurable Protection Threshold 3 Trip 40908 bit 5 Uint16 2 R True=1 False=0
Configurable Protection 5 Configurable Protection Threshold 4 Pickup 40908 bit 6 Uint16 2 R True=1 False=0
Configurable Protection 5 Configurable Protection Threshold 4 Trip 40908 bit 7 Uint16 2 R True=1 False=0
Configurable Protection 6 Configurable Protection Threshold 1 Pickup 40908 bit 8 Uint16 2 R True=1 False=0
Configurable Protection 6 Configurable Protection Threshold 1 Trip 40908 bit 9 Uint16 2 R True=1 False=0
Configurable Protection 6 Configurable Protection Threshold 2 Pickup 40908 bit 10 Uint16 2 R True=1 False=0
Configurable Protection 6 Configurable Protection Threshold 2 Trip 40908 bit 11 Uint16 2 R True=1 False=0
Configurable Protection 6 Configurable Protection Threshold 3 Pickup 40908 bit 12 Uint16 2 R True=1 False=0
Configurable Protection 6 Configurable Protection Threshold 3 Trip 40908 bit 13 Uint16 2 R True=1 False=0
Configurable Protection 6 Configurable Protection Threshold 4 Pickup 40908 bit 14 Uint16 2 R True=1 False=0
Configurable Protection 6 Configurable Protection Threshold 4 Trip 40908 bit 15 Uint16 2 R True=1 False=0
Configurable Protection 7 Configurable Protection Threshold 1 Pickup 40909 bit 0 Uint16 2 R True=1 False=0
Configurable Protection 7 Configurable Protection Threshold 1 Trip 40909 bit 1 Uint16 2 R True=1 False=0
Configurable Protection 7 Configurable Protection Threshold 2 Pickup 40909 bit 2 Uint16 2 R True=1 False=0
Configurable Protection 7 Configurable Protection Threshold 2 Trip 40909 bit 3 Uint16 2 R True=1 False=0
Configurable Protection 7 Configurable Protection Threshold 3 Pickup 40909 bit 4 Uint16 2 R True=1 False=0
Configurable Protection 7 Configurable Protection Threshold 3 Trip 40909 bit 5 Uint16 2 R True=1 False=0
Configurable Protection 7 Configurable Protection Threshold 4 Pickup 40909 bit 6 Uint16 2 R True=1 False=0
Configurable Protection 7 Configurable Protection Threshold 4 Trip 40909 bit 7 Uint16 2 R True=1 False=0
Configurable Protection 8 Configurable Protection Threshold 1 Pickup 40909 bit 8 Uint16 2 R True=1 False=0
Configurable Protection 8 Configurable Protection Threshold 1 Trip 40909 bit 9 Uint16 2 R True=1 False=0
Configurable Protection 8 Configurable Protection Threshold 2 Pickup 40909 bit 10 Uint16 2 R True=1 False=0
Configurable Protection 8 Configurable Protection Threshold 2 Trip 40909 bit 11 Uint16 2 R True=1 False=0
Configurable Protection 8 Configurable Protection Threshold 3 Pickup 40909 bit 12 Uint16 2 R True=1 False=0
Configurable Protection 8 Configurable Protection Threshold 3 Trip 40909 bit 13 Uint16 2 R True=1 False=0
Configurable Protection 8 Configurable Protection Threshold 4 Pickup 40909 bit 14 Uint16 2 R True=1 False=0
Configurable Protection 8 Configurable Protection Threshold 4 Trip 40909 bit 15 Uint16 2 R True=1 False=0
Synchronizer Sync Failed Alarm 40910 bit 0 Uint16 2 R True=1 False=0
Network Load Share Unknown Network Load Share Protocol Version 40910 bit 1 Uint16 2 R True=1 False=0
Alarms Voltage Matching Active 40910 bit 2 Uint16 2 R True=1 False=0
Contact Inputs Start Input 40910 bit 3 Uint16 2 R True=1 False=0
Contact Inputs Stop Input 40910 bit 4 Uint16 2 R True=1 False=0
Contact Inputs Input 1 40910 bit 5 Uint16 2 R True=1 False=0
Contact Inputs Input 2 40910 bit 6 Uint16 2 R True=1 False=0
Contact Inputs Input 3 40910 bit 7 Uint16 2 R True=1 False=0
Contact Inputs Input 4 40910 bit 8 Uint16 2 R True=1 False=0
Contact Inputs Input 5 40910 bit 9 Uint16 2 R True=1 False=0
Contact Inputs Input 6 40910 bit 10 Uint16 2 R True=1 False=0
Contact Inputs Input 7 40910 bit 11 Uint16 2 R True=1 False=0
Contact Inputs Input 8 40910 bit 12 Uint16 2 R True=1 False=0
Contact Inputs Input 9 40910 bit 13 Uint16 2 R True=1 False=0
Contact Inputs Input 10 40910 bit 14 Uint16 2 R True=1 False=0
Contact Inputs Input 11 40910 bit 15 Uint16 2 R True=1 False=0
Contact Inputs Input 12 40911 bit 0 Uint16 2 R True=1 False=0
