9440500990 Rev D 261
DECS-250N PROFIBUS Communication
Instance Name Inst. # Type RW Key Name Unit Range
FVR Setpoints 72 Float R/W Exc Vol Setpoint GG V 0 - 75
FVR Setpoints 72 Float R/W Exc Vol Min Setpoint
Limit GG
% 0 - 150
FVR Setpoints 72 Float R/W Exc Vol Max Setpoint
Limit GG
% 0 - 150
FVR Setpoints 72 Float R/W Exc Vol
Preposition1 GG
V 0 - 75
FVR Setpoints 72 Float R/W Exc Vol
Preposition2 GG
V 0 - 75
FVR Setpoints 72 Float R/W Exc Vol
Preposition3 GG
V 0 - 75
VAR Setpoints 73 UINT32 R/W Gen Var Prepos
Mode1 GG
No
Unit
Maintain=0 Release=1
VAR Setpoints 73 UINT32 R/W Gen Var Prepos
Mode2 GG
No
Unit
Maintain=0 Release=1
VAR Setpoints 73 UINT32 R/W Gen Var Prepos
Mode3 GG
No
Unit
Maintain=0 Release=1
VAR Setpoints 74 Float R/W Sys Option Fine Adjust
Band GG
% 0 - 30
VAR Setpoints 74 Float R/W Gen Var Traverse
Rate GG
Sec 10 - 200
VAR Setpoints 74 Float R/W Gen Var Setpoint GG kvar 0 – 41.57
VAR Setpoints 74 Float R/W Gen Var Min Setpoint
Limit GG
% -100 - 100
VAR Setpoints 74 Float R/W Gen Var Max Setpoint
Limit GG
% -100 - 100
VAR Setpoints 74 Float R/W Gen Var
Preposition1 GG
kvar 0 – 41.57
VAR Setpoints 74 Float R/W Gen Var
Preposition2 GG
kvar 0 – 41.57
VAR Setpoints 74 Float R/W Gen Var
Preposition3 GG
kvar 0 – 41.57
PF Setpoints 75 UINT32 R/W Gen Pf Prepos
Mode1 GG
No
Unit
Maintain=0 Release=1
PF Setpoints 75 UINT32 R/W Gen PfP repos
Mode2 GG
No
Unit
Maintain=0 Release=1
PF Setpoints 75 UINT32 R/W Gen PfP repos
Mode3 GG
No
Unit
Maintain=0 Release=1
PF Setpoints 76 Float R/W Gen Pf Traverse Rate GG Sec 10 - 200
PF Setpoints 76 Float R/W Gen Pf Setpoint GG PF 0.5 – -0.5
PF Setpoints 76 Float R/W Gen Pf Min Setpoint
Limit GG
PF 0.5 – 1
PF Setpoints 76 Float R/W Gen Pf Max Setpoint
Limit GG
PF -1 - -0.5
PF Setpoints 76 Float R/W Gen Pf Preposition1 GG PF 0.5 – -0.5
PF Setpoints 76 Float R/W Gen PfPreposition2 GG PF 0.5 – -0.5
PF Setpoints 76 Float R/W Gen Pf Preposition3 GG PF 0.5 – -0.5
Aux Input Settings 77 UINT32 R/W Decs Aux Input
Mode GG
No
Unit
Voltage=0 Current=1
