222 9440500990 Rev D
Modbus™ Communication DECS-250N
Group Name Register Type Bytes R/W Unit Range
Per Unit Meter Vab Pickup 41416 Float 4 R n/a -10 - 10
Per Unit Meter Vbc Pickup 41418 Float 4 R n/a -10 - 10
Per Unit Meter Vca Pickup 41420 Float 4 R n/a -10 - 10
Per Unit Meter V Average Pickup 41422 Float 4 R n/a -10 - 10
Per Unit Meter Ia Pickup 41424 Float 4 R n/a -10 - 10
Per Unit Meter Ib Pickup 41426 Float 4 R n/a -10 - 10
Per Unit Meter Ic Pickcup 41428 Float 4 R n/a -10 - 10
Per Unit Meter I Average Picup 41430 Float 4 R n/a -10 - 10
Per Unit Meter kW Pickup 41432 Float 4 R n/a -10 - 10
Per Unit Meter kVA Pickup 41434 Float 4 R n/a -10 - 10
Per Unit Meter Kvar Pickup 41436 Float 4 R n/a -10 - 10
Per Unit Meter Positive Sequence Voltage
Pickup 41438 Float 4 R n/a -10 - 10
Per Unit Meter Negative Sequence Voltage
Pickup 41440 Float 4 R n/a -10 - 10
Per Unit Meter Positive Sequence Current
Pickup 41442 Float 4 R n/a -10 - 10
Per Unit Meter Negative Sequence Current
Pickup 41444 Float 4 R n/a -10 - 10
Per Unit Meter Bus Vab Pickup 41446 Float 4 R n/a -10 - 10
Per Unit Meter Bus Vbc Pickup 41448 Float 4 R n/a -10 - 10
Per Unit Meter Bus Vca Pickup 41450 Float 4 R n/a -10 - 10
Per Unit Meter Bus V Average Pickup 41452 Float 4 R n/a -10 - 10
Per Unit Meter Voltage Difference Pickup 41454 Float 4 R n/a -10 - 10
Per Unit Meter Power in Voltage Pickup 41456 Float 4 R n/a -10 - 10
Per Unit Meter Generator Frequency Pickup 41458 Float 4 R n/a -10 - 10
Per Unit Meter Bus Frequency Pickup 41460 Float 4 R n/a -10 - 10
Per Unit Meter Ifd Pickup 41462 Float 4 R n/a -10 - 10
Per Unit Meter Vfd Pickup 41464 Float 4 R n/a -10 - 10
Per Unit Meter Slip Frequency Pickup 41466 Float 4 R n/a -10 - 10
Per Unit Meter Icc Pickup 41468 Float 4 R n/a -10 - 10
Per Unit Meter AVR Setpoint Pickup 41470 Float 4 R n/a -10 - 10
Per Unit Meter FCR Setpoint Pickup 41472 Float 4 R n/a -10 - 10
Per Unit Meter FVR Setpoint Pickup 41474 Float 4 R n/a -10 - 10
Per Unit Meter Var Setpoint Pickup 41476 Float 4 R n/a -10 - 10
Power Meter Scaled PF 41478 Float 4 R Power
Factor -1 - 1
AEM Metering Analog Input 1 Raw Value 41480 Float 4 R Milliamp n/a
AEM Metering Analog Input 2 Raw Value 41482 Float 4 R Milliamp n/a
AEM Metering Analog Input 3 Raw Value 41484 Float 4 R Milliamp n/a
AEM Metering Analog Input 4 Raw Value 41486 Float 4 R Milliamp n/a
AEM Metering Analog Input 5 Raw Value 41488 Float 4 R Milliamp n/a
AEM Metering Analog Input 6 Raw Value 41490 Float 4 R Milliamp n/a
AEM Metering Analog Input 7 Raw Value 41492 Float 4 R Milliamp n/a
AEM Metering Analog Input 8 Raw Value 41494 Float 4 R Milliamp n/a
AEM Metering Analog Input 1 Scaled Value 41496 Float 4 R n/a n/a
AEM Metering Analog Input 2 Scaled Value 41498 Float 4 R n/a n/a
AEM Metering Analog Input 3 Scaled Value 41500 Float 4 R n/a n/a
AEM Metering Analog Input 4 Scaled Value 41502 Float 4 R n/a n/a
AEM Metering Analog Input 5 Scaled Value 41504 Float 4 R n/a n/a
AEM Metering Analog Input 6 Scaled Value 41506 Float 4 R n/a n/a
AEM Metering Analog Input 7 Scaled Value 41508 Float 4 R n/a n/a
AEM Metering Analog Input 8 Scaled Value 41510 Float 4 R n/a n/a
