9440500990 Rev D 237
DECS-250N Modbus™ Communication
Name Register Type
Byte
s
R/W Unit Range
PF Mode Traverse Rate 47637 Float 4 R W Second 10 - 200
FCR Mode Setpoint Pre-Position 47639 Float 4 R W Amp Setpoint adjustment range
determined by registers 47655
and 47663.
AVR Mode Setpoint Pre-Position 47641 Float 4 R W Volt Setpoint adjustment range
determined by registers 47657
and 47665.
Var Mode Setpoint Pre-Position in kvar 47643 Float 4 R W Kvar Setpoint adjustment range
determined by registers 47659
and 47667.
PF Mode Setpoint Pre-Position 47645 Float 4 R W Power
Factor Setpoint adjustment range
determined by registers 47661
and 47669.
FCR Mode Setpoint Step Size 47647 Float 4 R n/a n/a
AVR Mode Setpoint Step Size 47649 Float 4 R n/a n/a
Var Mode Setpoint Step Size 47651 Float 4 R n/a n/a
PF Mode Setpoint Step Size 47653 Float 4 R n/a n/a
FCR Mode Setpoint Adjustable Minimum 47655 Float 4 R W Percent 0 - 120
AVR Mode Setpoint Adjustable Minimum 47657 Float 4 R W Percent 70 - 120
Var Mode Setpoint Adjustable Minimum 47659 Float 4 R W Percent -100 – 100
PF Mode Setpoint Adjustable Minimum 47661 Float 4 R W Power
Factor 0.5 - 1
FCR Mode Setpoint Adjustable Maximum 47663 Float 4 R W Percent 0 - 120
AVR Mode Setpoint Adjustable Maximum 47665 Float 4 R W Percent 70 - 120
Var Mode Setpoint Adjustable Maximum 47667 Float 4 R W Percent -100 – 100
PF Mode Setpoint Adjustable Maximum 47669 Float 4 R W Power
Factor -1 – -0.5
Minimum Value for FCR Adjustable Maximum 47671 Float 4 R n/a n/a
Minimum Value for AVR Adjustable Maximum 47673 Float 4 R n/a n/a
Minimum Value for Var Adjustable Maximum 47675 Float 4 R n/a n/a
Mini Value for PF Adjustable Max 47677 Float 4 R n/a n/a
Max Value for FCR Adjustable Max 47679 Float 4 R n/a n/a
Max Value for AVR Adjustable Max 47681 Float 4 R n/a n/a
Max Value for Var Adjustable Max 47683 Float 4 R n/a n/a
Max Value for PF Adjustable Max 47685 Float 4 R n/a n/a
Step Size for FCR Adjustable Max 47687 Float 4 R n/a n/a
Step Size for AVR Adjustable Max 47689 Float 4 R n/a n/a
Step Size for Var Adjustable Max 47691 Float 4 R n/a n/a
Step Size for PF Adjustable Max 47693 Float 4 R n/a n/a
FCR Pre-Position Mode 47695 Uint16 2 R W n/a Maintain=0 Release=1
AVR Pre-Position Mode 47696 Uint16 2 R W n/a Maintain=0 Release=1
Var Pre-Position Mode 47697 Uint16 2 R W n/a Maintain=0 Release=1
PF Pre-Position Mode 47698 Uint16 2 R W n/a Maintain=0 Release=1
FCR Minimum Setpoint 47699 Float 4 R n/a Setpoint adjustment range
determined by registers 47655
and 47529.
AVR Minimum Setpoint 47701 Float 4 R n/a Setpoint adjustment range
determined by registers 47657
and 47525.
Var Minimum Setpoint 47703 Float 4 R n/a Setpoint adjustment range
determined by registers 47659
and Rated VA.
PF Minimum Setpoint 47705 Float 4 R n/a Range determined by register
47661.
FCR Maximum Setpoint 47707 Float 4 R n/a Setpoint adjustment range
determined by registers 47663
and 47529.
