9440500990 Rev D 267
DECS-250N PROFIBUS Communication
Instance Name Inst. # Type RW Key Name Unit Range
SCL Settings 120 Float R/W Scl Pri Time Hi GG Sec 0 - 60
SCL Settings 120 Float R/W Scl Pri No Response
Time GG
Sec 0 - 10
SCL Settings 120 Float R/W Scl Sec Ref Hi GG Amp 0 - 66000
SCL Settings 120 Float R/W Scl Sec Ref Lo GG Amp 0 - 66000
SCL Settings 120 Float R/W Scl Sec Time Hi GG Sec 0 - 60
SCL Settings 120 Float R/W Scl Sec No Response
Time GG
Sec 0 - 10
SCL Settings 120 Float R/W Reserved n/a n/a
SCL Settings 120 Float R/W Reserved n/a n/a
SCL Settings 120 Float R/W Reserved n/a n/a
SCL Settings 120 Float R/W Reserved n/a n/a
SCL Settings 120 Float R/W Reserved n/a n/a
VAR Limiter Settings 121 UINT32 R/W Var Limit Enable GG No
Unit
DISABLED=0 ENABLED=1
VAR Limiter Settings 122 Float R/W Var Limit Pri Delay GG Sec 0 - 300
VAR Limiter Settings 122 Float R/W Var Limit Pri
Setpoint GG
% 0 - 200
VAR Limiter Settings 122 Float R/W Var Limit Sec Delay GG Sec 0 - 300
VAR Limiter Settings 122 Float R/W Var Limit Sec
Setpoint GG
% 0 - 200
OEL Scaling 123 UINT32 R/W Oel Scale Enable GG No
Unit
DISABLED=0
Auxiliary Input=1
AEM RTD 1=2
AEM RTD 2=3
AEM RTD 3=4
AEM RTD 4=5
AEM RTD 5=6
AEM RTD 6=7
AEM RTD 7=8
AEM RTD 8=9
OEL Scaling 124 Float R/W Oel Scale Summing
Signal1 GG
V -10 - 10
OEL Scaling 124 Float R/W Oel Scale Summing
Signal2 GG
V -10 - 10
OEL Scaling 124 Float R/W Oel Scale Summing
Signal3 GG
V -10 - 10
OEL Scaling 124 Float R/W Oel Scale Summing
Scale1 GG
% 0 - 200
OEL Scaling 124 Float R/W Oel Scale Summing
Scale2 GG
% 0 - 200
OEL Scaling 124 Float R/W Oel Scale Summing
Scale3 GG
% 0 - 200
OEL Scaling 124 Float R/W Oel Scale Takeover
Signal1 GG
V -10 - 10
OEL Scaling 124 Float R/W Oel Scale Takeover
Signal2 GG
V -10 - 10
