254 9440500990 Rev D
PROFIBUS Communication DECS-250N
Instance Name Inst. # Type RW Key Name Unit Range
AEM Analog Input Status 35 UINT8 R AEMPROTECTION5
THRESH3 TRIP Not tripped-0, Tripped=1
AEM Analog Input Status 35 UINT8 R AEMPROTECTION5
THRESH4 TRIP Not tripped-0, Tripped=1
AEM Analog Input Status 35 UINT8 R AEMPROTECTION6
THRESH1 TRIP Not tripped-0, Tripped=1
AEM Analog Input Status 35 UINT8 R AEMPROTECTION6
THRESH2 TRIP Not tripped-0, Tripped=1
AEM Analog Input Status 35 UINT8 R AEMPROTECTION6
THRESH3 TRIP Not tripped-0, Tripped=1
AEM Analog Input Status 35 UINT8 R AEMPROTECTION6
THRESH4 TRIP Not tripped-0, Tripped=1
AEM Analog Input Status 35 UINT8 R AEMPROTECTION7
THRESH1 TRIP Not tripped-0, Tripped=1
AEM Analog Input Status 35 UINT8 R AEMPROTECTION7
THRESH2 TRIP Not tripped-0, Tripped=1
AEM Analog Input Status 35 UINT8 R AEMPROTECTION7
THRESH3 TRIP Not tripped-0, Tripped=1
AEM Analog Input Status 35 UINT8 R AEMPROTECTION7
THRESH4 TRIP Not tripped-0, Tripped=1
AEM Analog Input Status 35 UINT8 R AEMPROTECTION8
THRESH1 TRIP Not tripped-0, Tripped=1
AEM Analog Input Status 35 UINT8 R AEMPROTECTION8
THRESH2 TRIP Not tripped-0, Tripped=1
AEM Analog Input Status 35 UINT8 R AEMPROTECTION8
THRESH3 TRIP Not tripped-0, Tripped=1
AEM Analog Input Status 35 UINT8 R AEMPROTECTION8
THRESH4 TRIP Not tripped-0, Tripped=1
AEM RTD Input Meter 36 Float R RtdInput1RawValue GG Ohm 7.1 – 18.73 or 80.31 – 194.1 (cu or
pt)
AEM RTD Input Meter 36 Float R RtdInput2RawValue GG Ohm 7.1 – 18.73 or 80.31 – 194.1 (cu or
pt)
AEM RTD Input Meter 36 Float R RtdInput3RawValue GG Ohm 7.1 – 18.73 or 80.31 – 194.1 (cu or
pt)
AEM RTD Input Meter 36 Float R RtdInput4RawValue GG Ohm 7.1 – 18.73 or 80.31 – 194.1 (cu or
pt)
AEM RTD Input Meter 36 Float R RtdInput5RawValue GG Ohm 7.1 – 18.73 or 80.31 – 194.1 ohms
(cu or pt)
AEM RTD Input Meter 36 Float R RtdInput6RawValue GG Ohm 7.1 – 18.73 or 80.31 – 194.1 (cu or
pt)
AEM RTD Input Meter 36 Float R RtdInput7RawValue GG Ohm 7.1 – 18.73 or 80.31 – 194.1 ohms
(cu or pt)
AEM RTD Input Meter 36 Float R RtdInput8RawValue GG Ohm 7.1 – 18.73 or 80.31 – 194.1 (cu or
pt)
AEM RTD Input Meter 36 Float R RtdInput1ScaledValue GG Deg F n/a
AEM RTD Input Meter 36 Float R RtdInput2ScaledValue GG Deg F n/a
AEM RTD Input Meter 36 Float R RtdInput3ScaledValue GG Deg F n/a
AEM RTD Input Meter 36 Float R RtdInput4ScaledValue GG Deg F n/a
AEM RTD Input Meter 36 Float R RtdInput5ScaledValue GG Deg F n/a
AEM RTD Input Meter 36 Float R RtdInput6ScaledValue GG Deg F n/a
AEM RTD Input Meter 36 Float R RtdInput7ScaledValue GG Deg F n/a
AEM RTD Input Meter 36 Float R RtdInput8ScaledValue GG Deg F n/a
AEM RTD Input Status 37 UINT8 R AEMCONFIG RTD INPUT 1
OUT OF RANGE Value in range=0, Value out of
range=1
AEM RTD Input Status 37 UINT8 R AEMCONFIG RTD INPUT 2
OUT OF RANGE Value in range=0, Value out of
range=1
AEM RTD Input Status 37 UINT8 R AEMCONFIG RTD INPUT 3
OUT OF RANGE Value in range=0, Value out of
range=1
AEM RTD Input Status 37 UINT8 R AEMCONFIG RTD INPUT 4
OUT OF RANGE Value in range=0, Value out of
range=1
