Configuration DECS-250N
A Generator Voltage Rating: Adjustable from 1 to 500,000 Vac in 1 Vac increments.
B Generator Frequency Rating: Select 50 or 60 Hz.
C Generator PF (Power Factor): Adjustable from –0.5 to 0.5 in 0.001 increments.
D Generator Voltamperes: Adjustable from 0 to 1,000,000 kVA in 0.01 kVA increments.
E Generator Current: Read-only value calculated from the generator VA and voltage.
F Generator Power: Read-only value calculated from the generator voltage, current, and PF.
G Generator Reactive Power: Read-only value calculated from the generator VA and PF.
H Field Voltage No Load: Adjustable from 1 to 264 Vdc in 0.1 Vdc increments.
I Field Current No Load: Adjustable from 0.1 to 20 Adc in 0.1 Adc increments.
J Field Voltage Full Load: Adjustable from 1 to 264 Vdc in 0.1 Vdc increments.
K Field Current Full Load: Adjustable from 0.1 to 20 Adc in 0.1 Adc increments.
L Pole Ratio: Adjustable from 0 to 10 in 0.01 increments.
M Calculator: Choose number of exciter and generator poles to calculate pole ratio.
N Bus Voltage: Adjustable from 1 to 500,000 Vac in 1 Vac increments.
O Power Input Voltage: Adjustable from 1 to 480 V in .01 increments.
P Inverted Output: Check box to enable inversion, uncheck to disable inversion.
Sensing Transformer Ratings and Configuration
BESTCOMSPlus Navigation Path: Settings Explorer, System Parameters, Sensing Transformers
HMI Navigation Path: Settings, System Parameters, Sensing Transformers
DECS-250N configuration includes entry of the primary and secondary values for the transformers that
supply generator and bus sensing values to the DECS-250N. These configuration settings are illustrated
in Figure 150.
Generator PT
Voltage settings for the generator PT primary A and secondary B windings establish the nominal PT
voltages expected by the DECS-250N. ABC or ACB phase rotation C can be accommodated. Options for
the generator voltage sensing connections D include single-phase (across phases C and A) and three-
phase sensing using three-wire connections.
Generator CTs
Current settings for the generator CT primary E and secondary F windings establish the nominal CT current
values expected by the DECS-250N. DECS-250N sensing current can be obtained from a single phase or
all three generator phases
G .
Bus PT
Voltage settings for the bus PT primary H and secondary I windings establish the nominal bus PT voltages
expected by the DECS-250N. Options for the bus voltage sensing connections J include single-phase
(across phases A and C) and three-phase sensing using three-wire delta connections.
