238 9440500990 Rev D
Modbus™ Communication DECS-250N
Name Register Type
Byte
s
R/W Unit Range
AVR Maximum Setpoint 47709 Float 4 R n/a Setpoint adjustment range
determined by registers 47665
and 47525.
Var Maximum Setpoint 47711 Float 4 R n/a Setpoint adjustment range
determined by registers 47667
and Rated VA.
PF Maximum Setpoint 47713 Float 4 R n/a Range determined by register
47669.
Reserved 11 47715-
740 C6 Filler 52 n/a n/a n/a
Soft Start Threshold 47741 Float 4 R W Percent 0 - 90
Soft Start Duration 47743 Float 4 R W Second 1 - 7200
Underfrequency Corner Frequency 47745 Float 4 R W Hertz 40 - 75
Slope of Underfrequency Curve 47747 Float 4 R W n/a 0 - 3
Width of Voltage Matching Window 47749 Float 4 R W Percent 0 - 20
Voltage Matching Reference 47751 Float 4 R W Percent 0 - 700
Fine Voltage Adjust Band 47753 Float 4 R W Percent 0 - 30
Time Required for Loss of Sensing 47755 Float 4 R W Second 0 - 30
Loss of Sensing Level Under Balanced
Conditions 47757 Float 4 R W Percent 0 - 100
Loss of Sensing Level Under Unbalanced
Conditions 47759 Float 4 R W Percent 0 - 100
Reserved 12 47761-
800 C7 Filler 80 n/a n/a n/a
On-line High OEL Level 47801 Float 4 R W Amp 0 - 30
Time Allowed for On-line High OEL Level 47803 Float 4 R W Second 0 - 10
On-line Medium OEL Level 47805 Float 4 R W Amp 0 - 20
Time Allowed for On-line Medium OEL Level 47807 Float 4 R W Second 0 - 120
On-line Low OEL Level 47809 Float 4 R W Amp 0 - 15
Reserved 13 47811 Float 4 R W var 0 - 99
Time Allowed for Off-line High OEL 47813 Float 4 R W Second 0 - 10
Off-line High OEL Level 47815 Float 4 R W Amp 0 - 30
Off-line Low OEL Level 47817 Float 4 R W Amp 0 - 15
First UEL Point kW Value 47819 Float 4 R W kilowatt 0 – 1.5 • Rated kVA
Second UEL Point kW Value 47821 Float 4 R W kilowatt 0 – 1.5 • Rated kVA
Third UEL Point kW Value 47823 Float 4 R W kilowatt 0 – 1.5 • Rated kVA
Fourth UEL Point kW Value 47825 Float 4 R W kilowatt 0 – 1.5 • Rated kVA
Fifth UEL Point kW Value 47827 Float 4 R W kilowatt 0 – 1.5 • Rated kVA
First UEL Point kvar Value 47829 Float 4 R W kilovar 0 – 1.5 • Rated kVA
Second UEL Point kvar Value 47831 Float 4 R W kilovar 0 – 1.5 • Rated kVA
Third UEL Point kvar Value 47833 Float 4 R W kilovar 0 – 1.5 • Rated kVA
Fourth UEL Point kvar Value 47835 Float 4 R W kilovar 0 – 1.5 • Rated kVA
Fifth UEL Point kvar Value 47837 Float 4 R W kilovar 0 – 1.5 • Rated kVA
SCL High Limit Level 47839 Float 4 R W Amp 0 - 66000
Time Allowed at SCL High Limit Level 47841 Float 4 R W Second 0 - 60
SCL Low Limit Level 47843 Float 4 R W Amp 0 - 66000
Takeover OEL Offline High Limit Level 47845 Float 4 R W Amp 0 - 30
Takeover OEL Offline Low Limit Level 47847 Float 4 R W Amp 0 - 15
Takeover OEL Offline Time Dial 47849 Float 4 R W n/a 0.1 - 20
Takeover OEL Online High Limit Level 47851 Float 4 R W Amp 0 - 30
Takeover OEL Online Low Limit Level 47853 Float 4 R W Amp 0 - 15
Takeover OEL Online Time Dial 47855 Float 4 R W n/a 0.1 - 20
Reserved 14 47857-
860 C8 Filler 8 n/a n/a n/a
