9440500990 Rev D 211
DECS-250N Modbus™ Communication
Group Name Register Type Bytes R/W Range
27P Block 40904 bit 11 Uint16 2 R True=1 False=0
27P Pickup 40904 bit 12 Uint16 2 R True=1 False=0
27P Trip 40904 bit 13 Uint16 2 R True=1 False=0
59P Block 40904 bit 14 Uint16 2 R True=1 False=0
59P Pickup 40904 bit 15 Uint16 2 R True=1 False=0
59P Trip 40905 bit 0 Uint16 2 R True=1 False=0
81O Block 40905 bit 1 Uint16 2 R True=1 False=0
81O Pickup 40905 bit 2 Uint16 2 R True=1 False=0
81O Trip 40905 bit 3 Uint16 2 R True=1 False=0
81U Block 40905 bit 4 Uint16 2 R True=1 False=0
81U Pickup 40905 bit 5 Uint16 2 R True=1 False=0
81U Trip 40905 bit 6 Uint16 2 R True=1 False=0
Gen Below 10 Hz Block 40905 bit 7 Uint16 2 R True=1 False=0
Gen Below 10 Hz Pickup 40905 bit 8 Uint16 2 R True=1 False=0
Gen Below 10 Hz Trip 40905 bit 9 Uint16 2 R True=1 False=0
40Q Block 40905 bit 10 Uint16 2 R True=1 False=0
40Q Pickup 40905 bit 11 Uint16 2 R True=1 False=0
40Q Trip 40905 bit 12 Uint16 2 R True=1 False=0
32R Block 40905 bit 13 Uint16 2 R True=1 False=0
32R Pickup 40905 bit 14 Uint16 2 R True=1 False=0
32R Trip 40905 bit 15 Uint16 2 R True=1 False=0
Configurable Protection 1 Configurable Protection Threshold 1 Pickup 40906 bit 0 Uint16 2 R True=1 False=0
Configurable Protection 1 Configurable Protection Threshold 1 Trip 40906 bit 1 Uint16 2 R True=1 False=0
Configurable Protection 1 Configurable Protection Threshold 2 Pickup 40906 bit 2 Uint16 2 R True=1 False=0
Configurable Protection 1 Configurable Protection Threshold 2 Trip 40906 bit 3 Uint16 2 R True=1 False=0
Configurable Protection 1 Configurable Protection Threshold 3 Pickup 40906 bit 4 Uint16 2 R True=1 False=0
Configurable Protection 1 Configurable Protection Threshold 3 Trip 40906 bit 5 Uint16 2 R True=1 False=0
Configurable Protection 1 Configurable Protection Threshold 4 Pickup 40906 bit 6 Uint16 2 R True=1 False=0
Configurable Protection 1 Configurable Protection Threshold 4 Trip 40906 bit 7 Uint16 2 R True=1 False=0
Configurable Protection 2 Configurable Protection Threshold 1 Pickup 40906 bit 8 Uint16 2 R True=1 False=0
Configurable Protection 2 Configurable Protection Threshold 1 Trip 40906 bit 9 Uint16 2 R True=1 False=0
Configurable Protection 2 Configurable Protection Threshold 2 Pickup 40906 bit 10 Uint16 2 R True=1 False=0
Configurable Protection 2 Configurable Protection Threshold 2 Trip 40906 bit 11 Uint16 2 R True=1 False=0
Configurable Protection 2 Configurable Protection Threshold 3 Pickup 40906 bit 12 Uint16 2 R True=1 False=0
Configurable Protection 2 Configurable Protection Threshold 3 Trip 40906 bit 13 Uint16 2 R True=1 False=0
Configurable Protection 2 Configurable Protection Threshold 4 Pickup 40906 bit 14 Uint16 2 R True=1 False=0
Configurable Protection 2 Configurable Protection Threshold 4 Trip 40906 bit 15 Uint16 2 R True=1 False=0
Configurable Protection 3 Configurable Protection Threshold 1 Pickup 40907 bit 0 Uint16 2 R True=1 False=0
Configurable Protection 3 Configurable Protection Threshold 1 Trip 40907 bit 1 Uint16 2 R True=1 False=0
Configurable Protection 3 Configurable Protection Threshold 2 Pickup 40907 bit 2 Uint16 2 R True=1 False=0
Configurable Protection 3 Configurable Protection Threshold 2 Trip 40907 bit 3 Uint16 2 R True=1 False=0
Configurable Protection 3 Configurable Protection Threshold 3 Pickup 40907 bit 4 Uint16 2 R True=1 False=0
Configurable Protection 3 Configurable Protection Threshold 3 Trip 40907 bit 5 Uint16 2 R True=1 False=0
Configurable Protection 3 Configurable Protection Threshold 4 Pickup 40907 bit 6 Uint16 2 R True=1 False=0
Configurable Protection 3 Configurable Protection Threshold 4 Trip 40907 bit 7 Uint16 2 R True=1 False=0
Configurable Protection 4 Configurable Protection Threshold 1 Pickup 40907 bit 8 Uint16 2 R True=1 False=0
Configurable Protection 4 Configurable Protection Threshold 1 Trip 40907 bit 9 Uint16 2 R True=1 False=0
Configurable Protection 4 Configurable Protection Threshold 2 Pickup 40907 bit 10 Uint16 2 R True=1 False=0
Configurable Protection 4 Configurable Protection Threshold 2 Trip 40907 bit 11 Uint16 2 R True=1 False=0
Configurable Protection 4 Configurable Protection Threshold 3 Pickup 40907 bit 12 Uint16 2 R True=1 False=0
Configurable Protection 4 Configurable Protection Threshold 3 Trip 40907 bit 13 Uint16 2 R True=1 False=0
