Modbus™ Communication
DECS-250N
Group
Name
Register
Type
Bytes
R/W
Unit
Range
DECS Control
Startup Primary Soft-start Time
42670
Float
4
R W
Second
1 - 7200
DECS Control
Startup Secondary Soft-start Bias
42672
Float
4
R W
Percent
0 - 90
DECS Control
Startup Secondary Soft-start Time
42674
Float
4
R W
Second
1 - 7200
DECS Control
System Option PF to Droop kW Threshold
42676
Float
4
R W
Percent
0 - 30
Protection Settings
Table 32. Protection Settings Group Parameters
Group
Name
Register
Type
Sz
R/W
Unit
Range
Field Overvoltage
Primary Mode
43100
Uint32
4
R W
n/a
Disabled=0 Enabled=1
Field Overvoltage
Primary Pickup
43102
Float
4
R W
V
Disabled=0, 1 - 325
Field Overvoltage
Primary Time Delay
43104
Float
4
R W
ms
Instantaneous=0, 200 - 30000
Field Overvoltage
Secondary Mode
43106
Uint32
4
R W
n/a
Disabled=0 Enabled=1
Field Overvoltage
Secondary Pickup
43108
Float
4
R W
V
Disabled=0, 1 - 325
Field Overvoltage
Secondary Time Delay
43110
Float
4
R W
ms
Instantaneous=0, 200 - 30000
Field Overcurrent
Primary Mode
43112
Uint32
4
R W
n/a
Disabled=0 Enabled=1
Field Overcurrent
Primary Pickup
43114
Float
4
R W
Amp
Disabled=0, 0 - 22
Field Overcurrent
Primary Time Delay
43116
Float
4
R W
ms
Instantaneous=0, 5000 - 60000
Field Overcurrent
Secondary Mode
43118
Uint32
4
R W
n/a
Disabled=0 Enabled=1
Field Overcurrent
Secondary Pickup
43120
Float
4
R W
Amp
Disabled=0, 0 - 22
Field Overcurrent
Secondary Time Delay
43122
Float
4
R W
ms
Instantaneous=0, 5000 - 60000
Exciter Diode Monitor
Exciter Open Diode Enable
43124
Uint32
4
R W
n/a
Disabled=0 Enabled=1
Exciter Diode Monitor
Exciter Shorted Diode Enable
43126
Uint32
4
R W
n/a
Disabled=0 Enabled=1
Exciter Diode Monitor
Exciter Diode Disable Level
43128
Float
4
R W
%
0 - 100
Exciter Diode Monitor
Exciter Open Diode Pickup
43130
Float
4
R W
%
0 - 100
Exciter Diode Monitor
Exciter Open Diode Time Delay
43132
Float
4
R W
Sec
10 – 60
Exciter Diode Monitor
Exciter Shorted Diode Pickup
43134
Float
4
R W
%
0 - 100
Exciter Diode Monitor
Exciter Shorted Diode Time
Delay
43136
Float
4
R W
Sec
5 – 30
Exciter Diode Monitor
Exciter Pole Ratio
43138
Float
4
R W
n/a
Disabled=0, 1 – 10
Power Input Failure
Mode
43140
Uint32
4
R W
n/a
Disabled=0 Enabled=1
Power Input Failure
Time Delay
43142
Float
4
R W
Sec
0 - 10
Loss Of Sensing
Mode
43144
Uint32
4
R W
n/a
Disabled=0 Enabled=1
Loss Of Sensing
Time Delay
43146
Float
4
R W
Sec
0 - 30
Loss Of Sensing
Voltage Balanced Level
43148
Float
4
R W
%
0 - 100
Loss Of Sensing
Voltage Unbalanced Level
43150
Float
4
R W
%
0 - 100
25
Mode
43152
Uint32
4
R W
n/a
Disabled=0 Enabled=1
25
Slip Angle
43156
Float
4
R W
Deg
1 - 99
25
Slip Frequency
43158
Float
4
R W
Hz
0.01 - 0.5
25
Voltage Difference
43160
Float
4
R W
%
0.1 - 50
25
Generator Frequency Greater
Than Bus Frequency
43162
Uint32
4
R W
n/a
Disabled=0 Enabled=1
25
Dead Voltage
43164
Float
4
R W
%
Disabled=0, 10 – 90
25
Live Voltage
43166
Float
4
R W
%
Disabled=0, 10 – 90
25
Dropout Delay
43168
Float
4
R W
ms
50 – 60000
25
Angle Compensation
43170
Float
4
R W
Deg
0 – 359.9
25
VMM Dead Line, Dead Aux
43172
Uint32
4
R W
n/a
Disabled=0 Enabled=1
25
VMM Dead Line, Live Aux
43174
Uint32
4
R W
n/a
Disabled=0 Enabled=1
25
VMM Live Line, Dead Aux
43176
Uint32
4
R W
n/a
Disabled=0 Enabled=1
27P
Primary Mode
43178
Uint32
4
R W
n/a
Disabled=0 Enabled=1
27P
Primary Pickup
43180
Float
4
R W
V
Disabled=0, 1 - 600000
27P
Primary Time Delay
43182
Float
4
R W
ms
100 - 60000
