280 9440500990 Rev D
PROFIBUS Communication DECS-250N
Instance Name Inst. # Type RW Key Name Unit Range
Config Prot 3 192 Float R/W Threshold3Pickup GG No
Unit
-999999 - 999999
Config Prot 3 192 Float R/W Threshold3
Activation Delay GG
Sec 0 - 300
Config Prot 3 192 Float R/W Threshold4Pickup GG No
Unit
-999999 - 999999
Config Prot 3 192 Float R/W Threshold4
Activation Delay GG
Sec 0 - 300
Config Prot 4 193 UINT32 R/W Param Selection GG No
Unit
Gen VAB=0 Gen VBC=1 Gen
VCA=2 Gen V Average=3 Bus
Freq=4 Bus VAB=5 Bus VBC=6 Bus
VCA=7 Gen Freq=8 Gen PF=9
KWH=10 KVARH=11 Gen IA=12
Gen IB=13 Gen IC=14 Gen I
Average=15 KW Total=16 KVA
Total=17 KVAR Total=18 EDM
Ripple=19 Exciter Field
Voltage=20 Exciter Field
Current=21 Auxilary Input
Voltage=22 Auxilary Input
Current (mA)=23 Setpoint
Position=24 Tracking Error=25
Neg Seq V=26 Neg Seq I=27 Pos
Seq V=28 Pos Seq I=29 PSS
Output=30 Analog Input 1=31
Analog Input 2=32 Analog Input
3=33 Analog Input 4=34 Analog
Input 5=35 Analog Input 6=36
Analog Input 7=37 Analog Input
8=38 RTD Input 1=39 RTD Input
2=40 RTD Input 3=41 RTD Input
4=42 RTD Input 5=43 RTD Input
6=44 RTD Input 7=45 RTD Input
8=46 Thermocouple 1=47
Thermocouple 2=48
Config Prot 4 193 UINT32 R/W Stop Mode Inhibit GG No
Unit
NO=0 YES=1
Config Prot 4 193 UINT32 R/W Threshold 1 Type GG No
Unit
Disabled=0 Over=1 Under=2
Config Prot 4 193 UINT32 R/W Threshold 2 Type GG No
Unit
Disabled=0 Over=1 Under=2
Config Prot 4 193 UINT32 R/W Threshold 3 Type GG No
Unit
Disabled=0 Over=1 Under=2
Config Prot 4 193 UINT32 R/W Threshold4 Type GG No
Unit
Disabled=0 Over=1 Under=2
Config Prot 4 194 Float R/W Hysteresis GG % 0 - 100
Config Prot 4 194 Float R/W Arming Delay GG Sec 0 - 300
Config Prot 4 194 Float R/W Threshold 1 Pickup GG No
Unit
-999999 - 999999
Config Prot 4 194 Float R/W Threshold1
Activation Delay GG
Sec 0 - 300
Config Prot 4 194 Float R/W Threshold2Pickup GG No
Unit
-999999 - 999999
Config Prot 4 194 Float R/W Threshold2
Activation Delay GG
Sec 0 - 300
Config Prot 4 194 Float R/W Threshold3Pickup GG No
Unit
-999999 - 999999
