Axxius 800 - Release 2.2
4-11
Configuration
Quick Configuration Reload
Quick Configuration Reload
The
print config
command can be used as a quick way to reload a configuration
into an Axxius unit, in the event that the configuration has been lost due to software
reload problems or operator error.
The download of the file generated by the
print config
command can be done by
direct connect to the RS-232 port or via Telnet, BUT the upload from the PC back to
the Axxius can only be done via direct RS-232 connection. The reason for this is that
there will not be an IP address in the Axxius because it is at the factory default at this
time.
The procedure described below is based on using Hyperterm.
Download Config File:
1. Connect to the unit using Hyperterm via the RS-232 port.
2. Type
config
(do not hit
[E
NTER
]
).
3. Select Transfer/Capture Text...
from the menu bar.
4. Name the file so that is can be accessed when needed.
