5-82 Axxius 800 - Release 2.2
CLI Commands
set
set (ds1 card) adpcm map
Use the set (ds1 card) adpcm map command to set voice compression map on the Quad
DS1 ADPCM card.
Syntax: set {adpcm_card-addr} adpcm {none|map1|map2|map3}
Example: set 5 adpcm map1
{adpcm_card-addr} - The slot number (1-6) that contains the Quad DS1 ADPCM card.
{none|map1|map2|map3}
none None will disable compression on the card. Default.
map1, map2 or map3 Map setting, see chart below
MAP 1 MAP 2 MAP 3
DS0 X-Port Backplane X-Port Backplane X-Port Backplane
Number Analog Bus Analog Bus Analog Bus
1 32n X1/2 32n X1/2 32n X1/2
2 32n X3/4 32n X3/4 32n X3/4
3 32n X5/6 32n X5/6 32n X5/6
4 32n X7/8 32n X7/8 32n X7/8
5 32n X9/10 32n X9/10 32n X9/10
6 32n X11/12 32n X11/12 32n X11/12
7 32n X14/15 32n X13/14 32n X13/14
8 32n X16/17 32n X15/16 32n X15/16
9 32n X18/19 32n X17/18 32n X17/18
10 32n X20/21 32n X19/20 32n X19/20
11 32n X22/23 32n X21/22 32n X21/22
12 32n X24 32n X23/24 32n X24
13 - Not Avail 32n 32n
14 32n 32n 32n
15 32n 32n 32n
16 32n 32n 32n
17 32n 32n 32n
18 32n 32n 32n
19 32n 32n 32n
20 32n 32n 32n
21 32n 32n 32n
22 32n 32n 32n
23 32n 32n - Not Avail
24 64n 32n 64n
