5-50 Axxius 800 - Release 2.2
CLI Commands
delete
delete (router-lan) static
Use the delete (router-lan) static commands to delete static elements from the specified LAN
interface.
delete (router-lan) static ip address
Use the delete (router-lan) static ip address command to delete a static IP address entry
from the specified LAN interface.
Syntax: add {rtr_lan-addr} static ip address {ip-addr}
Example: add 3:1 static ip address 195.168.201.140
{rtr_lan-addr}
The Router address is in the form {slot:port} or {slot "profile-name"}.
{ip-addr}
The IP address of the learned address table for the LAN, in the form of xxx.xxx.xxx.xxx,
where xxx is between 0-255.
slot Slot number (1-8) that contains the Router card
port Port number of the Router.
"profile-name" The profile name for the Router interface. Name must be enclosed
in quotes, with a maximum length of 11 characters
