Axxius 800 - Release 2.2

6-5

DS1 Controller Card

Technical Specifications

Management

l

Local

- RS-232 craft port interface drives up to 50 ft. (15.24 m) cable, and provides a

Command Line Interface (CLI) using ASCII terminal or PC with terminal
emulation software, modem using XMODEM or PPP sessions

l

Remote

- 10/100Base-TX Ethernet management port provides

• Local IP management connectivity

• RJ-45 connector

• 10/100Base-TX Ethernet link LED status indicator

• IP management over a dedicated DS0 bearer channel

- CLI management via the V.34 modem port on the Single Channel POTS with

Modem Service card

l

Integrated TFTP client for remote download of Controller software upgrades

l

SNMP agent for use with SNMP-based Element Management Systems

l

CLI offers three levels of password controlled security

DS1 Interface

l

Selectable four DS1 ports from the Connector Panel operating at 1.544 Mbps
± 50 bps

l

4 DS1 ports operating at 1.544 Mbps

l

Expansion to 36 DS1 ports in a single chassis using Quad DS1 Service Cards

l

SF (D4) and ESF framing, AMI or B8ZS line coding (DS1 operation)

l

Short-haul or long-haul loop settings for DS1

l

4 RJ-48C connectors located on the front of the Control Panel Interface Card

l

Integrates DS1 CSU functionality for direct connection to DS1 lines

l

Offers secondary solid-state fuseless protection to lightning and power cross
incidents.
