16-4 Axxius 800 - Release 2.2
V.35/.54 Card
Technical Specifications
Testing and Diagnostics (V.35/54 card)
l Addressable V.54 loop up and loop down (127-code) pattern generation/
detection
l 2047, 2
15
-1, 2
20
-1 and QRSS Test Patterns with error counter
Power
l 2 W maximum
Environment
In addition to the systems environment requirements, the following applies to the
V.35/54 (hardened) card. For additional information see Installation Environment on
page 2-3.
l Operating temperature range of the V.35/54 card: -40
°
to 149
°
F
(-40
°
to 65
°
C)
Physical
l Dimensions: 3.5 in. (H) x 0.75 in. (W) x 11.25 in. (D)
8.9 cm (H) x 1.9 cm (W) x 28.6 cm (D)
l Weight: 4.6 oz. (0.13 kg)
Accessories
Sub-miniature DB-26 to Winchester adapter cables are required to interface DTE with
the Dual V.35 card. Gender refers to the Winchester connector. One cable per port.
l P/N 005-0008 V.35 Male 10 Ft. (3.05 m) cable
l P/N 005-0009 V.35 Male 25 Ft. (7.62 m) cable
l P/N 005-0010 V.35 Male 50 Ft. (15.24 m) cable
l P/N 005-0011 V.35 Female 10 Ft. (3.05 m) cable
