Axxius 800 - Release 2.2
12-7
Power Supply
Installing/Replacing a Power Supply
Installing/Replacing a Power Supply
Install a Power Supply
The Axxius has redundant Power Supply System capability. The unit will run on one
power supply (and not be redundant) or can have 2 power supplies installed.
1. Connect the power cord to the associated connector (Power 1 or Power 2).
See Power Connections on page 3-7 for details on the Power Connector.
Note: this step is for installation only.
2. Simply slide the Power Supply into the Power 1 or Power 2 slot following card
guides.
3. Press gently on the faceplate of the power supply to ensure that the connector
on the power supply is fully mated to its mating connector on the backplane.
4. Both front panel LEDs should illuminate green.
Remove a Power Supply
Remove power supply by grasping faceplate at top and bottom and pulling power
supply straight out of the case. If this is a redundant system, this will not effect power
to the system.
Front
Power
1
Power
2
