Axxius 800 - Release 2.2 1-7
Base Platform
Technical Specifications
Capacities
l 2 x Power Supply cards
l 2 x DS3 or DS1 Controller cards
l 1 x Control Panel Interface card
l 8 x universal service cards
l 36 T1 ports (8 x Quad T1 service cards + 4 on DS1 Controller)
l 1536 DS0 non-blocking cross-connect capability
Redundancy
l 1:1 Controllers (automatic switchover) for provisioning redundancy
l 1:7 T1 interface protection ratio with Low-Speed Interface Protection card
l 1 + 1 Power Supplies
Control Panel Interfaces
l 4 x RJ-48C jacks (Quad DS1 Controller)
l 4 x SMB connectors (2 TX, 2 RX) for DS3 Controller
l 1 x 10/100Base-TX Ethernet RJ-45 jack
l 1 x RS-232 DB9 female jack
l 1 x ACO switch
l Status indicators for critical, major, minor and ACO
Rear Chassis Interfaces
l 8 x 16 wire-wrap pins
l 2 x 2 pin modular plug for dual DC power feeds
l 2 x 3 wire-wrap pins for BITS clock input (primary and secondary)
l 2 x 6 pin modular receptacle for alarm relay outputs
l Audible alarm outputs (3) critical, major and minor
l Visible alarm outputs (3) critical, major and minor
l 2 x 10 pin modular receptacle for environmental monitor inputs
l 2 x 3/16 inch threaded stud for grounding
