9-8 Axxius 800 - Release 2.2
ISDN BRI Card
Connector Pinouts
Connector Pinouts
Wire-Wrap Pinout 2 Wire Services
The following pinout applies to the wire-wrap pinout for the slot of the ISDN BRI card.
Wire-Wrap Pins Description
T1 Channel 1 Transmit Tip
R1 Channel 1 Transmit Ring
T2 Channel 2 Transmit Tip
R2 Channel 2 Transmit Ring
T3 Channel 3 Transmit Tip
R3 Channel 3 Transmit Ring
T4 Channel 4 Transmit Tip
R4 Channel 4 Transmit Ring
T5 Channel 5 Transmit Tip
R5 Channel 5 Transmit Ring
T6 Channel 6 Transmit Tip
R6 Channel 6 Transmit Ring
T7 Channel 7 Transmit Tip
R7 Channel 7 Transmit Ring
T8 Channel 8 Transmit Tip
R8 Channel 8 Transmit Ring
