Carrier Access Network Device Axxius 800 User Manual
Page 246

5-146
Axxius 800 - Release 2.2
CLI Commands
set
set (router-lan) rip ipx
Use the set (router-lan) rip ipx command to specify the IPX RIP and SAP for the specified
LAN interface.
Syntax:
set {rtr_lan-addr} rip ipx {both|neither|recv|send}
Example:
set 2:1 rip ipx send
The example will set RIP and SAP on the local LAN interface on slot 2 to send.
{rtr_lan-addr}
The Router address is in the form {slot:port} or {slot "profile-name"}.
{both|neither|recv|send}
slot
The slot number (1-8) that contains the Router card.
port
Port number of the Router.
"profile-name"
The profile name for the Router interface. Name must be enclosed
in quotes, with a maximum length of 11 characters.
both
Enable IPX RIP (or IPX RIP and SAP) in both directions.
neither
Shut IPX RIP (or IPX RIP and SAP) off completely.
recv
Enable IPX RIP (or IPX RIP and SAP) in the receive direction
only.
send
Enable IPX RIP (or IPX RIP and SAP) in the send direction.
