14-4

Axxius 800 - Release 2.2

Quad T1 & Quad DS1/E1 Card

Technical Specifications

Technical Specifications

Controller Software Required

l

Release 1.0 or higher is required for the Quad T1service card

T1 Interface

l

4 T1 ports operating at 1.544 Mbps (DS1) or 2.048 Mbps (E1)

±

50 bps

l

Expansion to 36 T1 ports in a single chassis using Quad T1 Service cards

l

SF (D4) or ESF framing, AMI or B8ZS line coding

l

Short-haul or long-haul loop settings for T1

l

4 RJ-48C front interface access (Control Panel Interface card) or rear wire-wrap
pins (selectable)

l

T1 Line Interface: T1-CSU or T1-DSX (field selectable)

l

Line Build Out (DSX-1): 655 feet

l

Receive Sensitive (DS1): 0 to -22 dB @ 772KHz ALBO

l

Output Level (DS1): Selectable at 0 to -22 dB

l

Jitter: Meets AT&T Pub. TR 62411

l

Solid-state fuseless overvoltage and overcurrent T1 line protection

l

Channel status LEDs

l

Less than 3 ms signaling latency

l

Less than 10 ms overall Axxius 800 system signaling latency

Network Standards

l

RFC 2495

l

ANSI T1.403-1995, T1.231-1993

l

AT&T TR 62411, TR 54016

l

ITU G.703, G.706, G.823, I.431

l

TBR 12 and 13
