Carrier Access Network Device Axxius 800 - Manual (Page 248)

5-148 Axxius 800 - Release 2.2
CLI Commands
set
set (router-lan) stp port cost
Use the set (router-lan) stp port cost command to configure Spanning Tree path cost
value for this bridge port.
Syntax: set {rtr_lan-addr} stp port cost {port-cost-value}
Example: set 3:1 stp port cost 100
Sets the Spanning Tree port cost value at 100, on the Router in slot 3.
{rtr_lan-addr}
The Router address is in the form {slot:port} or {slot "profile-name"}.
{port-cost-value}
The value can range from 1 to 65535, higher values represent slower data paths. For a 100
Mb LAN a value of 19 is recommended. For a 10 Mb LAN a value of 100 is recommended.
set (router-lan) stp port priority
Use the set (router-lan) stp port priority command to configure Spanning Tree priority
value for this bridge port.
Syntax: set {rtr_lan-addr} port priority
{port-priority-value}
Example: set 3:1 stp port priority 128
The example will set the STP port priority to 128, on the Router in slot 3.
{rtr_lan-addr}
The Router address is in the form {slot:port} or {slot "profile-name"}.
{port-priority-value}
Spanning Tree port priority for this bridge port. Range from 0 to 255, with a default of 128.
slot Slot number (1-8) that contains the Router card.
port Port number of the Router.
"profile-name" The profile name for the Router interface. Name must be enclosed
in quotes, with a maximum length of 11 characters.
slot Slot number (1-8) that contains the Router card.
port Port number of the Router.
"profile-name" The profile name for the Router interface. Name must be enclosed
in quotes, with a maximum length of 11 characters.
