Axxius 800 - Release 2.2 5-205
CLI Commands
show
Total: 0
Static MAC Address Settings for LocalUnit:
Total: 0
LAN Filters Enabled for LocalUnit:
Forward Mode: Forward ALL Frames NOT Matching Filters
Filter Type Source/Dest Filter Name
Total: 0
LAN MAC Address Filters Defined for LocalUnit:
Total: 0
LAN Protocol Filters Defined for LocalUnit:
Total: 0
LAN Custom Filters Enabled Defined for LocalUnit:
Total: 0
Settings for TSR WAN RemoteUnit:
State: Enabled
IP Settings:
Mode: Route
WAN Network Updates: Never
GRE Tunneling: Disabled
IPX Settings:
Mode: Blocked
Other Settings:
Mode: Blocked
NAT Gateway: Disabled
WAN Numbered IP: No
{rtr_lan-addr}
The Router address is in the form {slot:port} or {slot "profile-name"}.
slot The slot number (1-8) that contains the Router card.
port Port number of the Router.
"profile-name" The profile name for the Router interface. Name must be enclosed in
quotes, with a maximum length of 11 characters.
