Axxius 800 - Release 2.2 5-163
CLI Commands
set
set (router-wan) stp
Use the set (router-wan) stp commands to configure the Spanning Tree Protocol on the
specified WAN interface.
set (router-wan) stp enable/disable
Use the set (router-wan) stp enable/disable command to enable and disable Spanning
Tree Protocol on this interface. To enable Spanning Tree on an interface it must first be
enabled globally with the set (router) stp enable command and the WAN must be set to
bridge the IP protocol.
Syntax: set {rtr_card-addr} {"wan-name"} stp {disable|enable}
Example: set 3 stp enable
The example will enable Spanning Tree on this interface.
{rtr_card-addr}
The slot number (1-8) that contains the Router card.
{"wan-name"}
The WAN interface to modify. The name must be enclosed in quotes.
{disable|enable}
disable Disable Spanning Tree on this interface.
enable Enable Spanning Tree on this interface.
