Axxius 800 - Release 2.2 3-15
Electrical Installation and Cabling
Chassis Connections
Standard Telco Color Code
Circuit connections are made at the wire-wrap connectors. The pinouts are as follows:
Pair Pin Location Function Color Code
1 26
1
Tip Channel 1
Ring Channel 1 White/Blue
Blue/White
2 27
2
Tip Channel 2
Ring Channel 2 White/Orange
Orange/White
3 28
3
Tip Channel 3
Ring Channel 3 White/Green
Green/White
4 29
4
Tip Channel 4
Ring Channel 4 White/Brown
Brown/White
5 30
5
Tip Channel 5
Ring Channel 5 White/Slate
Slate/White
6 31
6
Tip Channel 6
Ring Channel 6 Red/Blue
Blue/Red
7 32
7
Tip Channel 7
Ring Channel 7 Red/Orange
Orange/Red
8 33
8
Tip Channel 8
Ring Channel 8 Red/Green
Green/Red
9 34
9
Tip Channel 9
Ring Channel 9 Red/Brown
Brown/Red
10 35
10 Tip Channel 10
Ring Channel 10 Red/Slate
Slate/Red
11 36
11 Tip Channel 11
Ring Channel 11 Black/Blue
Blue/Black
12 37
12 Tip Channel 12
Ring Channel 12 Black/Orange
Orange/Black
13 38
13 Tip Channel 13
Ring Channel 13 Black/Green
Green/Black
14 39
14 Tip Channel 14
Ring Channel 14 Black/Brown
Brown/Black
