5-40

Axxius 800 - Release 2.2

CLI Commands

connect

connect

Use the connect command to create two-way connections between any DS0 channels of the
service or controller cards.

Syntax:

connect

{slot:port|slot:port:channel}

{slot:port|slot:port:channel}

Use the disconnect command to delete connections.

Example:

connect A:2:1-24 3:1

Connects all 24 channels on port address #2 (DS1) on the controller card
(slot A) to port address #1 V.35 in slot 3.

{slot:port|slot:port:channel}

Channel Associated Signaling (CAS) Conversions

Cross-connects are done at a DS0 level. The following rules need to be kept in mind while
performing cross-connects for the voice cards.

slot

A for the controller card, or 1-8 for service cards.

port

Port number or range.

channel

Channel number or range, for T1 ports.

DS0

FXO Analog

LS

GS

DPT

LSCPD DPT = Dial Pulse Termination

T1 DS0

EMDW = E&M Delayed Wink start

LS

Y

N

N

Y

EMI = E&M Immediate start

GS

N

Y

N

N

EMICPD = E&M Immediate Start with Calling
Party Disconnect

EMDW

N

N

N

N

EMW = E&M Wink start

EMI

N

N

Y

N

GS = Ground Start

EMICPD

N

N

N

N

LS = Loop Start

EMW

N

N

N

N

LSCPD = Loop Start Calling Party Disconnect
