Axxius 800 - Release 2.2
16-7
V.35/.54 Card
Connector Pinouts
Connector Pinouts
V.35 DCE (DB-26)
The V.35 DCE data port connection is made at the sub-miniature DB-26 connector on
the Axxius 800 using the 10-foot, 25-foot, or 50 foot Carrier Access DTE V.35 cable
equipped with a sub-miniature DB-26 connector and a 34-pin Winchester connector.
This cable is used to connect the Axxius 800 V.35 DCE data ports to synchronous V.35
DTE data sources up to 1.536 Mbps, all rates (1-24) Nx56 or Nx64 channel-rate
progression.
The Carrier Access Corporation V.35 data cables are built according to the pin
assignments listed below:
Sub-miniature
DB-26
Signal
Winchester 34-pin
(female)
Paired
Signals
1 (+ Shield)
←
Protective Ground
→
A
7
←
Signal Ground
→
B
2
←
Transmit Data A
P
14
←
Transmit Data B
S
3
Receive Data A
→
R
16
Receive Data B
→
T
4
←
RTS
C
20
←
DTR
H
5
CTS
→
D
6
DSR
→
E
12
Test Mode
→
K
8
CD (RLSD)
→
F
11
←
External Clock A
U
24
←
External Clock B
W
10
Xmit Clock A
→
Y
23
Xmit Clock B
→
AA
