Electrical Installation and Cabling
Chassis Connections
Chassis Connections
The following illustrations show all connectors on the rear, as well as the front
(interface card) of the Axxius 800.
Back of the Axxius 800:
l Audible Alarms
l External Alarm Inputs
l Visible Alarms
l Input (power, P1 and P2)
l Bits Clock 1 and 2
l Wire-Wrap Connectors (slots 1-8)
l Ground Lugs
Ground Terminals
Audible
Power Connectors Visible
Clock
A and B
External
Alarm
Slot 1-8 Wire-Wrap Connectors
A and B Alarms
Alarms
Inputs
