7-4

Axxius 800 - Release 2.2

DS3 Controller Card

Technical Specifications

Management

l

Local
- RS-232 craft port interface drives up to 50 ft. (15.24 m) cable, and provides a

Command Line Interface (CLI) using ASCII terminal or PC with terminal
emulation software, modem using XMODEM or PPP sessions

l

Remote
- 10/100Base-TX Ethernet management port provides

• Local IP management connectivity

• RJ-45 connector

• 10/100Base-TX link LED status indicator

• IP management over a dedicated DS0 bearer channel

- CLI management via the V.34 modem port on the Order Wire Single Channel

POTS with Modem Service card

- GUI management from NetworkValet EMS

l

Integrated TFTP client for remote download of controller software upgrades

l

SNMP agent for use with NetworkValet

l

CLI offers three levels of password controlled security

Network DS3 Interface

l

Line Rate: 44.746 Mbps ± 20 ppm

l

Line Code: B3ZS Bipolar with three zero substitution

l

Framing format: M23 and C-bit parity

l

Transmit impedance: 75

± 5%, unbalanced

l

Transmit jitter attenuation: Meets ANSI T1.102 requirements

l

Transmit amplitude: Meets ANSI T1.102 pulse mask with 0.36 to 0.85 Vp
requirements

l

Transmit length (cable): 500 ft. (152.4 m) to crossconnect

l

Receive sensitivity: -10 dB w/r DSX-3 120 mVp to 900 mVp input range with
automatic gain control circuit
