Axxius 800 - Release 2.2 5-79
CLI Commands
set
id Set the DS1 circuit identification name. This is the same as dsx1Circuit
Identifier from DS1 MIB transmission vendor’s identification. String
text must be enclosed in quotes
.
Example: set {ds1-addr} id {"id-name"}
{id-name} = transmission vendor’s ID, up to 30 characters, in quotes.
lbo Set the Line Build Out (LBO) to one of the following: Note: this
options is not applicable on a DS1 within a DS3.
1 DSX-1 equalization for 0-133 feet (equivalent to CSU
attenuation for LBO of 0dB)
2 DSX-1 equalization for 133-266 feet
3 DSX-1 equalization for 266-399 feet
4 DSX-1 equalization for 399-533 feet
5 DSX-1 equalization for 533-655 feet
6 CSU attenuation for LBO of -7.5dB
7 CSU attenuation for LBO of -15dB
8 CSU attenuation for LBO of -22.5dB
line Turn a line loopback to the DS1 interface on or off. If the line command
is not used, the default for line loopback is loopdown.
loopdown Disable the line loopback
loopup Enable a DS1 line loopback toward the DS1 drop
linecode Set the DS1 interface line coding to one of the following. If the linecode
command is not used, the default for linecode is B8ZS.
Note: this options is not applicable on a DS1 within a DS3.
ami Alternate Mark Inversion line coding
b8zs Binary 8 Zero Substitution line coding.
loopdetect Enable detection of CSU loop code (10000 - loopup; 100 - loopdown)
on Enable detection
off Disable detection
payload Apply a payload loopback to the DS1 interface. If the payload
command is not used, the default for payload loopback is loopdown.
loopdown Disable the payload loopback
loopup Enable the payload loopback
