Page 81: Setup of adpcm set up a v.35 port

Axxius 800 - Release 2.2
4-9
Configuration
Basic System Setup
Setup of ADPCM
Set Up a V.35 Port
Use the following commands to set up a V.35 port.
Command
Description
Connect T1 cable to port 1 of the ADPCM service card
set {adpcm_card-addr}
{none|map1|map2|map3}
Enable compressing by selecting Map type. Note:
none disables compression.
show (adpcm_card-addr}
Displays the status of the card, and the mapping.
connect 2:1:1-12 2:4:1-12
Set ADPCM cross-connects. The example
connects all 24 channels of the ADPCM to the 12
channels of the T1 (now compressed) on port 4.
This example is with map2
show connect {2:1)
Displays the connections made above.
Command
Description
set {v35-addr} cts
{cd|high|low|rts}
Set the Clear to Send operation mode. See set
(v35) command for details.
set {v35-addr} data
{invert|normal}
Set the data mode. See set (v35) command for
details.
set {v35-addr} clock
{source|external}
Set the clock mode. See set (v35) command for
details.
set {v35-addr} speed
{56K|64K}
Set the speed. See set (v35) command for details.
set {v35-addr} txclkinv
{invert|normal}
Set the transmit clock inversion mode. See set
(v35) command for details.
set {v35-addr} rxclkinv
{invert|normal}
Set the receive clock inversion mode. See set
(v35) command for details.
